1D-7
I･pulse F1 Series
F1-82-0603 (D type)
P 3
No. Code No. Parts Name Q'ty Parts No.
※2 LG4-M1A30-012 HOLD LEVER ASSY 1 AS3-A08-8190-B
1 K87-M111G-100 PUSH PIN 1 AS2-A08-8190-C
2 LG4-M1A1K-000 LEVER AXIS PIN 1 FTA-A08-8130-B
3 LG4-M1A1A-001 COVER PLATE 1 FTA-A08-8149-C
※1 4 LG4-M1AA2-001 SPRING CONNECTOR ASS
Y
1 FTA-A08-8151-5B
5 LG4-M1A31-000 HOLD LEVER M 1 FTA-A08-8190-B
6 LG4-M1A32-000 HOLD LEVER S 1 FTA-A08-8190-1B
7 LG4-M1A34-001 CLAMP LEVER 1 FTA-A08-8191-C
8 LG4-M1A3M-000 SCREW COIL SPRING 1
FTA-A08-8191-SCSp
9 LG4-M1A3A-000 HINGE PIN 1 1 FTA-A08-8191-1
※2 10 LG4-M1A35-001 CLANK ARM 1 FTA-A08-8192-B
11 LG4-M1A3B-000 HINGE PIN 2 1 FTA-A08-8192-1
12 LG4-M1A36-000 ARM 1 FTA-A08-8193
13 LG4-M1A33-000 LINK PLATE 1 FTA-A08-8194
14 LG4-M1A3L-000 CLANK ARM AXIS PIN 1 FTA-A08-8195
15 LG4-M1A37-010 ADJUST CLAMP PIN 1 FTA-A08-8196
16 LG4-M1A3K-001 CLAMP LEVER AXIS PIN 1 FTA-A08-8197-B
17 LG4-M1A38-000 LINK PIN T 1 FTA-A08-8198
18 LG4-M1A39-000 LINK PIN U 1 FTA-A08-8199
19 LG4-M1ADC-000 SCREW,PAN HEAD+ 2 3MC-7-P
20 K87-M111S-000 SCREW,FLAT HEAD+ 2 3MK-6-P
21 K87-M111T-000 SCREW,SET 1 3MY-3-F
22 K87-M111R-000 SCREW ,SET 2 3MY-5-F
23 K87-M111U-000 SCREW FLANGE NUT 2 3MH-FS
24 K87-M21BN-000 SCREW NUT 2 3MH-P
25 K87-M21BM-000 SPRING LOCK WASHER 1 3MU-P
26 K87-M1115-000 CIRCULAR RIVET 1 2-10
27
28
29
30
31
32
33
※1 F1-82-0603-000401D∼
※2 F1-82-0603-000481D∼
1D-6
1D-7
I･pulse F1 Series
F1-82-0603(D type)
P 4
No. Code No. Parts Name Q'ty Parts No.
LG4-M3A40-011 TAPE GUIDE PLATE ASSY 1 AS -A08-8119-63C
1
LG4-M3A41-011 TAPE GUIDE PLATE 1 FTA-A08-8119-63C
2
LG4-M3A42-000 SHUTTER PLATE 1 FTA-A08-8120-63
3
LG4-M1A45-000 SHUTTER GUIDE PIN 2 FTA-A08-8121
4 LG4-M1A44-001 SHUTTER PUSH SPRING 1 FTA-A08-8122-B
5
LG4-M3A43-010 SHUTTER GUARD PLATE 1 FTA-A08-8123-63B
6
LG4-M1A4L-000 T.G. GUIDE SCREW 1 FTA-A08-8124
7
LG4-M1A47-000 T.G. GUIDE PIN 1 FTA-A08-8125
8
LG4-M3A49-000 ADJUST PLATE 1 FTA-A08-8126-63
9
LG4-M1A46-000 LOCK LEVER 1 FTA-A08-8127-B
10 LG4-M1A48-001
TAPE GUIDE PUSH SPRIN
G
1 FTA-A08-8127-50
11
LG4-M1A4K-000 T.G.A. GUIDE PIN 1 FTA-A08-8129
12
K87-M1547-000 SCREW,TRUSS HEAD 2 T2M-2.5-P
13
LG4-M3AD3-000 SPRING LOCK WASHER 2 2MU
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
