I･pulse　 F1　Series

F1-12 (H type)

P 1

No. Code No. Parts Name Q'ty Parts No.

※1

LG4-M4A10-040 BODY ASSY

1

AS -A12-8101-D

LG4-M4A1M-010 MAIN LEVER ASSY

1

AS3-A12-8131

1 K87-M111G-100 PUSH PIN 1

CTF-M08- 325

2

LG4-M1A1L-000 THRUST WASHER

1

CTF- 53- 38-02

3 K87-M111H-200 BACK STOPPER 1

FTA-A08-1114

4

LG4-M4A1T-000

ARM AXIS PIN 1 FTA-A12-8134

※1 5

LG4-M4A11-030

BODY 1

FTA-A12-8101-D

6 LG4-M1A12-500

MAIN GUIDE PIN 1 FTA-E08-8502

7 LG4-M1A13-500

LOCATE PIN R 1 FTA-E08-8503

8 LG4-M1A14-500

LOCATE PIN F 1 FTA-E08-8504

9

LG4-M4A15-000 PLUG HOLDER GUIDE

1

FTA-A12-8105

10

LG4-M1A16-000 PLUG HOLDER

1

FTA-A08-8106

11

KW1-M221F-100 STOPPER PIN

1

CTF-M12- 313

12

LG4-M4A19-001 BACK STOPPER RE. SP.

1

FTA-A08-6164-1600

13

K87-M211B-000 BACK STOPPER AXIS

1

CTF-M12- 315

14

LG4-M1A1K-000 LEVER AXIS PIN

1

FTA-A08-8130-B

15

LG4-M4A1N-000 MAIN LEVER

1

FTA-A12-8131

16

LG4-M4A1P-000 ARM

1

FTA-A12-8135-B

17

LG4-M4A1S-000

ARM AXIS PIN 1

FTA-A12-8139

18 K87-M1186-000

BARB CONNECTOR

1

BF3BU

19

LG4-M1AB2-000 PLUG

1

MA-MC05PM

20

LG4-M4ABA-010 AIR HOSE

1

U3B-167

21 K87-M23B3-000

SCREW,SET　

3

3MY-5

22 K87-M111R-000

SCREW,SET　

6

3MY-5-F

23

K87-M1115-000 CIRCULAR RIVET

1

2-10

24

LG4-M1AD2-000 CIRCLIP C

1

STW-7

25

26

27

28

29

30

31

32

※1…F1-12-007818H～

I･pulse　 F1　Series

F1-12 (H type)

P 2

No. Code No. Parts Name Q'ty Parts No.

KW1-M1120-000 SPROCKET ASSY 1 AS2-A08-1107-P4

LG4-M4A2A-010 RACKING LEVER ASSY 1

AS-A12-8117-C

LG4-M4A2M-000 RATCHET AXIS ASSY

1

AS-A12-8112

1 K87-M111C-000 PLANE WASHER 1

CTF-A08- 16-B

2

LG4-M4A2E-000

RACKING LEVER 1

FTA-A12-8108

3 K87-M112F-000 SPRING HOOK PIN 1

CTF-A08- 211-B2

4 K87-M112M-100 FLANGE A 1

CTF-A08- 712-1

5 LG4-M1A2F-000 SCREW COIL SPRING 1

FTA-A08-8111-1

6 K87-M1121-000 METAL 1

FTA-A08-1103

※1

7 KW1-M11BS-050

WASHER 1

FTA-A08-1103-005B

8 K87-M1122-000 RIVET 3

FTA-A08-1103-1

9 KW1-M1123-000 SPROCKET 1

FTA-A08-1104-B

10 K87-M1124-000 RATCHET 1

FTA-A08-1107-P4

11 K87-M112G-100 RACKING POLE 1

FTA-A08-1111

12

LG4-M1A2D-000 SHUTTER DRIVE PIN

1

FTA-A08-8109

13

LG4-M1A2C-000 RACKING POLE AXIS

1

FTA-A08-8110

14

LG4-M4A2N-000 RATCHET AXIS

1

FTA-A12-8112

15

LG4-M4A2P-000 FLANGE B

1

FTA-A12-8112-2

16

LG4-M4A2B-010 MAIN ARM

1

FTA-A12-8117-C

17

LG4-M4A1R-010 SUB ARM

1

FTA-A12-8138-B

18 K87-M11BF-000

SCREW,FLAT HEAD

1

P2MK-4-IB

19

20

21

22

23

24

25

26

27

28

29

30

31

※1…F1-12-007818H～
