I･pul se F1 Series F1-84 (F type) P 2 No. Code No. Parts Name Q'ty Parts No. KW1-M1120-000 SPROCKET ASSY 1 AS2-A08-1107-P4 LG4-M1A2A-001 RACKING LEVER ASSY 1 AS1-A08-8117-B LG4-M1A2M-000 RATCHET AXIS ASSY 1 AS -A08-…
3F-3
I･pulse F1 Series
F1-84 (F type)
P 2
No. Code No. Parts Name Q'ty Parts No.
KW1-M1120-000 SPROCKET ASSY 1 AS2-A08-1107-P4
LG4-M1A2A-001 RACKING LEVER ASSY 1 AS1-A08-8117-B
LG4-M1A2M-000 RATCHET AXIS ASSY 1 AS -A08-8112
1 K87-M111C-000 PLANE WASHER 1 CTF-A08- 16-B
2 K87-M112F-000 SPRING HOOK PIN 1 CTF-A08- 211-B2
3 K87-M112M-100 FLANGE A 1 CTF-A08- 712-1
4 LG4-M1A2F-000 SCREW COIL SPRING 1 CTF-M08- 511-1
5 K87-M1121-000 METAL 1 FTA-A08-1103
6 K87-M1122-000 RIVET 3 FTA-A08-1103-1
7 KW1-M1123-000 SPROCKET 1 FTA-A08-1104-B
8 K87-M1124-000 RATCHET 1 FTA-A08-1107-P4
9 K87-M112G-100 RACKING POLE 1 FTA-A08-1111
10 LG4-M1A2E-000 RACKING LEVER 1 FTA-A08-8108
11 LG4-M1A2D-000 SHUTTER DRIVE PIN 1 FTA-A08-8109
12 LG4-M1A2C-000 RACKING POLE AXIS 1 FTA-A08-8110
13 LG4-M1A2N-000 RATCHET AXIS 1 FTA-A08-8112
14 LG4-M1A2P-000 FLANGE B 1 FTA-A08-8112-2
15 LG4-M1A2B-000 MAIN ARM 1 FTA-A08-8117-B
16 K87-M11BF-000 SCREW,FLAT HEAD 1 P2MK-4-IB
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
