I･pulse　 F1　Series

F1-84 （F type)

P 6

Code No. Parts Name Q'ty Parts No.

LG4-M1A87-000

TENSION LEVER　ASSY

1 AS -A08-8160-B

LG4-M1A8E-000

IDLER ROLLER ASSY

1 AS -A08-8162

LG4-M1A86-000

I．ROLLER ALL ASSY

1 AS1-A08-8162

LG4-M1A82-012

INDEKING LEVER ASSY

1 AS3-A08-8164

LG4-M1A8D-000

DRIVE ROLLER ASSY

1 AS -A08-8170

LG4-M1A81-003 D．ROLLER ALL ASSY 1 AS1-A08-8170

1 K87-M111C-000

PLANE WASHER

1 CTF-A08- 16-B

2 K87-M117B-000

PLANE WASHER

2 CTF-M08- 76-B

3 KW1-M11A3-001

LOWER GUIDE PLATE,L

1 FTA-A08-1179-C

4 LG4-M1A62-000

METAL SHAFT

1 FTA-A08-8155

5 LG4-M1A8C-000

LEVER METAL

1 FTA-A08-8158-B

6 LG4-M1A63-500

LEVER AXIS PIN

1 FTA-E08-8559

7 LG4-M1A64-500

WASHER

1 FTA-E08-8559-1

8 LG4-M1A65-010

TENSION LEVER

1 FTA-A08-8160-B

9 LG4-M4A8B-000

TENSION LEVER RE. SP.

1 FTA-A12-8160-700

10 LG4-M1A66-010

ROLLER AXIS

1 FTA-A08-8163-B

11 LG4-M1A83-000

INDEKING LEVER

1 FTA-A08-8164

12 LG4-M1A8A-000

INDEKING LEVER RE. SP.

1 FTA-A08-8164-440

13 LG4-M1A84-010

ARM STUD

1 FTA-A08-8166-B

14 LG4-M1A85-000

ROLLER

1 FTA-A08-8167

※1

15 LG4-M1A6M-010

MIDDLE GUIDE PLATE T

1 FTA-A08-8177-D

16 LG4-M1A6P-011

LOWER GUIDE PLATE,R

1 FTA-A08-8178-C

17 K87-M11BF-000

SCREW,FLAT HEAD+

1 P2MK-4-IB

18

K87-M11BB-000

SCREW,FLAT HEAD+

2 P2.6MK-5-IB

19 K87-M111W-000 SCREW,PAN HEAD+ 1 3MC-5-P

20

K87-M111N-000 SCREW,PAN HEAD+ 6 3MC-3-P

21 K87-M11BE-000 THRUST WASHER 4 3V-0.5-8-P

22

23

24

25

26

27

28

※1…F1-84-039856F～

I･pulse　 F1　Series

F1-84 (F type)

P 7

No. Code No. Parts Name Q'ty Parts No.

LG4-M1A90-000

REEL HOLDER ASSY

1

AS -201720

1

LG4-M1AA1-002 CONTROL BOARD 1

FTA-A08-8151-FCB

2

LG4-M1A6R-010

CONTROL BOARD COLLAR 3

FTA-A08-8152-B

3

LG4-M1A6S-001

CONTROL BOARD COVER

1

FTA-A08-8153-B

4

LG4-M1A91-000

REEL HOLDER

1

201720

5 LG4-M1A92-000

CLAMP ARM

1

201721

6 K87-M111N-000 SCREW,PAN HEAD+ 3

3MC-3-P

7 K87-M111W-000 SCREW,PAN HEAD+ 3

3MC-5-P

8 LG4-M1ADF-000

SCREW,BAIND HEAD+

3

3M-10-P-P-Bi

9

LG4-M1AC1-0x0 SERIAL NO. STICKER 1

FTA-A08-8150-SNS

10 KW1-M11AA-000

ROHS STICKER

1

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30
