4C-11
I･pulse F1 Series
F1-12(C type)
P 5
No. Code No. Parts Name Q'ty Parts No.
LG4-M4A60-020 BACK PLATE ASSY
1
AS3-A12-8150-C
1 K87-M116A-100 SPRING HOOK PIN 4 CTF-M08- 166-B
2
LG4-M4A6G-000 TAPER ROLLER
1 FTA-A12-8172-1
3
LG4-M4A6H-000 TAPER ROLLER
2 FTA-A12-8172-2
4
LG4-M1A72-000 CONNECT PIN
1 FTA-A08-8146
5
LG4-M1A71-000 ROD CONNECT
1 FTA-A08-8147
6
LG4-M4A61-010 BACK PLATE
1 FTA-A12-8150-C
7
LG4-M1AA3-000 MICRO SWITCH ASSY
1 FTA-A08-8151-6
8
LG4-M1AA4-000 VALVE HARNESS ASSY
1 FTA-A08-8151-7
9
LG4-M4A6A-000 ROLLER AXIS T
2 FTA-A12-8173
10
LG4-M4A6C-000 LEAF T
2 FTA-A12-8173-1
11
LG4-M4A6B-000 ROLLER AXIS U
1 FTA-A12-8174
12
LG4-M4A6D-000 LEAF U
1 FTA-A12-8174-1
13
LG4-M4A6N-000 MIDDLE GUIDE PLATE C
1 FTA-A12-8176-C
14
LG4-M1AB1-000 VAL PACK CYLINDER
1 BDA10×15-327W
15 K87-M1186-000
BARB CONNECTOR
1 BF3BU
16
LG4-M4A73-000 ADJUST PLATE
1 FTA-A12-8151-C
17
LG4-M4A6E-000
ADJUST PLATE STUD 2 FTA-A12-8151-1
18
LG4-M4A6F-000
SET PIN 1 FTA-A12-8152
19 K87-M2387-000
PLANE WASHER
2
CTF- 54- 66-1
20
K87-M111N-000 SCREW,PAN HEAD+
3 3MC-3-P
21
LG4-M1ADC-000 SCREW,PAN HEAD+
1 3MC-7-P
22
LG4-M4ADE-000 SCREW,FLAT HEAD+
1
3MK-7-P
23 KW1-M45BG-000
SCREW,FLAT HEAD+
1 3MK-10-P
24
LG4-M4ADD-000 SCREW,FLAT HEAD+
3 3MK-15-P
25 K87-MB01H-000 BOLT,HEX SOCKET HEAD 2 3MX-8-P
26 K87-M23BA-000 BOLT,HEX SOCKET HEAD 2 4MX-8-P
27 K87-M21BM-000 SPRING LOCK WASHER 2
3MU
28
LG4-M4AD3-000
SPRING LOCK WASHER 2
4MU
29 K87-M11D7-000
CIRCLIP E
1 E-32
30
31
32
33
4C-10
4C-11
I･pulse F1 Series
F1-12(C type)
P 6
No. Code No. Parts Name Q'ty Parts No.
LG4-M4A81-000
D．ROLLER ALL ASSY 1 AS3-A12-1170-B
LG4-M4A82-000 INDEKING LEVER ASSY
1 AS-A12-8164-B
KW1-M229F-000
DRIVE ROLLER ASSY
1 AS-A12-1170-B
KW1-M229L-000
IDLER ROLLER ASSY
1 AS-A12-1162-B
1 K87-M111C-000
PLANE WASHER
1 CTF-A08- 16-B
2 K87-M117B-000
PLANE WASHER
1 CTF-M08- 76-B
3 KW1-M229D-000
LEVER METAL
1 FTA-A12-1168
4 KW1-M229R-000
COLLAR
1 FTA-A12-1161
5 KW1-M229M-000
IDLE ROLLER
1 FTA-A12-1162-B
6 KW1-M229G-000
DRIVE ROLLER
1 FTA-A12-1170-B
7 KW1-M119H-000
COVER PLATE
1 FTA-A08-1171-B
8 KW1-M22A3-001
LOWER GUIDE PLATE , L
1 FTA-A12-1179-B
9
LG4-M4A62-000 METAL SHAFT
1 FTA-A12-8155
10
LG4-M4A63-000 LEVER AXIS PIN
1 FTA-A12-8159
11
LG4-M4A64-000 COLLAR
1 FTA-A12-8159-1
12
LG4-M4A65-000 TENSION LEVER
1 FTA-A12-8160
13
LG4-M4A8B-000
TENSION LEVER RETURN SPRING
1 FTA-A12-8160-700
14 KW1-M226G-000
ROLLER AXIS
1 FTA-A12-1163
15
LG4-M4A83-000 INDEKING LEVER
1 FTA-A12-8164-B
16
LG4-M4A8A-000
INDEKING LEVER RETURN SPRING
1 FTA-A12-8164-260
17
LG4-M4A84-000 ARM STUD
1 FTA-A12-8166
18
LG4-M4A6M-000 MIDDLE GUIDE PLATE T
1 FTA-A12-8176-1B
19
LG4-M4A6P-010 LOWER GUIDE PLATE , R
1 FTA-A12-8178-C
20 KW1-M119B-000 ONE･WAY CLUTCH 1 OWC4-13-3.1-L
21 KW1-M229E-000 ONE･WAY CLUTCH 1 OWC8-16-5.5-L
22 K87-M11BF-000
SCREW , FLAT HEAD 精密＋ IB
1 P2MK-4-IB
23 K87-M11BB-000
SCREW , FLAT HEAD 精密＋ IB
1 P2.6MK-5-IB
24 K87-M21BB-000 SCREW , TRUSS HEAD ＋ 1 T2.6M-5-P
25
K87-M111N-000
SCREW , PAN HEAD ＋ 6 3MC-3-P
26 K87-M11BE-000 THRUST WASHER 4 3MV (3V-0.5-8-P)
27
28
29
30
