2-3
I･pulse F1 Series
F1-82-1005(C type)
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A10-011 BODY ASSY 1 AS -A08-8101
LG4-M1A1M-000 MAIN LEVER ASSY 1 AS -A08-8131
1
K87-M111D-000 PUSH PIN 1 CTF-M08- 25
2
K87-M111G-100 PUSH PIN 1 CTF-M08- 325
3
K87-M111H-200 BACK STOPPER 1 FTA-A08-1114
4
KW1-M114E-000 ARM AXIS PIN 1 FTA-A08-1134
5
LG4-M1A11-011 BODY 1 FTA-A08-8101
6
LG4-M1A12-000 MAIN GUIDE PIN 1 FTA-A08-8102
7 LG4-M1A13-000 LOCATE PIN R 1 FTA-A08-8103-B
8
LG4-M1A14-000 LOCATE PIN F 1 FTA-A08-8104-B
9
LG4-M1A15-000
PLUG HOLDER GUIDE RING
1 FTA-A08-8105
10
LG4-M1A16-000 PLUG HOLDER 1 FTA-A08-8106
11
LG4-M1A17-000 STOPPER PIN 1 FTA-A08-8113
12
LG4-M1A19-000
BACK STOPPER RETURN SPRING
1 FTA-A08-8114-300
13
LG4-M1A18-000 BACK STOPPER AXIS 1 FTA-A08-8115
14
LG4-M1A1K-000 LEVER AXIS PIN 1 FTA-A08-8130-B
15
LG4-M1A1N-000 MAIN LEVER 1 FTA-A08-8131
16
LG4-M1A1P-000 ARM 1 FTA-A08-8135
17
LG4-M1A1R-000 SUB ARM 1 FTA-A08-8138
18
LG4-M1A1S-000 SUB ARM GUIDE PIN 1 FTA-A08-8139
19
K87-M1186-000 BARB CONNECTOR 1 BF3BU
20
LG4-M1AB2-000 PLUG 1 MA-MC05PM
21
LG4-M1ABA-010 AIR HOSE 1 U3B-157
22
K87-M23B3-000 SCREW , SET 3 3MY-5
23
K87-M111X-000 SCREW , SET 1 3MY-4-F
24
K87-M111R-000 SCREW , SET 5 3MY-5-F
25
LG4-M1AD1-000 CIRCULAR RIVET 1 φ2-8
26
LG4-M1AD2-000 CIRCLIP C 1 STW-7
27
28
29
30
31
32
2-2
2-3
I･pulse F1 Series
F1-82-1005(C type)
No. Code No. Parts Name Q'ty Parts No.
KW1-M1320-000 SPROCKET ASSY 1 AS2-A08-1107-P2
LG4-M1A2A-000 RACKING LEVER ASSY 1 AS -A08-8117-B
LG4-M1A2M-000 RATCHET AXIS ASSY 1 AS -A08-8112
1
K87-M111C-000 PLANE WASHER 1 CTF-A08- 16-B
2
K87-M112B-200 RACKING LEVER 1 CTF-A08- 705-C
3
K87-M112F-000 SPRING HOOK PIN 1 CTF-A08- 211-B2
4
K87-M112M-100 FLANGE A 1 CTF-A08- 712-1
5
KW1-M452D-000 SCREW COIL SPRING 1 CTF-M08- 511-1
6
K87-M1121-000 METAL 1 FTA-A08-1103
7
K87-M1122-000 RIVET 3 FTA-A08-1103-1
8
KW1-M1123-000 SPROCKET 1 FTA-A08-1104-B
9
K87-M1324-000 RATCHET 1 FTA-A08-1107-P2
10
K87-M112G-100 RACKING POLE 1 FTA-A08-1111
11
LG4-M1A2D-000 SHUTTER DRIVE PIN 1 FTA-A08-8109
12
LG4-M1A2C-000 RACKING POLE AXIS 1 FTA-A08-8110
13
LG4-M1A2N-000 RATCHET AXIS 1 FTA-A08-8112
14
LG4-M1A2P-000 FLANGE B 1 FTA-A08-8112-2
15
LG4-M1A2B-000 MAIN ARM 1 FTA-A08-8117-B
16
K87-M11BF-000 SCREW , FLAT HEAD 1 P2MK-4-IB
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
