4F-5
I･pulse F1 Series
F1-12 (F type)
P 2
No. Code No. Parts Name Q'ty Parts No.
KW1-M1120-000 SPROCKET ASSY 1 AS2-A08-1107-P4
※１
LG4-M4A2A-010 RACKING LEVER ASSY 1
AS-A12-8117-C
LG4-M4A2M-000 RATCHET AXIS ASSY
1
AS-A12-8112
1 K87-M111C-000 PLANE WASHER 1
CTF-A08- 16-B
2
LG4-M4A2E-000
RACKING LEVER 1
FTA-A12-8108
3 K87-M112F-000 SPRING HOOK PIN 1
CTF-A08- 211-B2
4 K87-M112M-100 FLANGE A 1
CTF-A08- 712-1
5 LG4-M1A2F-000 SCREW COIL SPRING 1
FTA-A08-8111-1
6 K87-M1121-000 METAL 1
FTA-A08-1103
7 K87-M1122-000 RIVET 3
FTA-A08-1103-1
8 KW1-M1123-000 SPROCKET 1
FTA-A08-1104-B
9 K87-M1124-000 RATCHET 1
FTA-A08-1107-P4
10 K87-M112G-100 RACKING POLE 1
FTA-A08-1111
11
LG4-M1A2D-000 SHUTTER DRIVE PIN
1
FTA-A08-8109
12
LG4-M1A2C-000 RACKING POLE AXIS
1
FTA-A08-8110
13
LG4-M4A2N-000 RATCHET AXIS
1
FTA-A12-8112
14
LG4-M4A2P-000 FLANGE B
1
FTA-A12-8112-2
※１
15
LG4-M4A2B-010 MAIN ARM
1
FTA-A12-8117-C
※１
16
LG4-M4A1R-010 SUB ARM
1
FTA-A12-8138-B
17 K87-M11BF-000
SCREW,FLAT HEAD
1
P2MK-4-IB
18
19
20
21
22
23
24
25
26
27
28
29
30
31
※1．．．F1-12-4788F～
4F-4
4F-5
I･pulse F1 Series
F1-12 (F type)
P 3
No. Code No. Parts Name Q'ty Parts No.
LG4-M4A30-002
HOLD LEVER ASSY 1 AS5-A12-8190
1 K87-M111G-100 PUSH PIN 1
CTF-M08- 325
2 LG4-M1A17-000 STOPPER PIN 1 FTA-A08-8113
3
LG4-M1A1K-000
LEVER AXIS PIN 1
FTA-A08-8130-B
4
LG4-M1A1A-001
COVER PLATE 1
FTA-A08-8149-C
5
LG4-M1AA2-001 SP. CONNECTOR ASSY
1
FTA-A08-8151-5B
6
LG4-M4A31-000 HOLD LEVER M
1 FTA-A12-8190
7
LG4-M1A32-000 HOLD LEVER S
1 FTA-A08-8190-1B
8
LG4-M4A34-001 CLAMP LEVER
1 FTA-A12-8191-B
9 LG4-M1A3M-000 SCREW COIL SPRING 1
FTA-A08-8191-SCSp
10 LG4-M1A3A-000 HINGE PIN 1
1
FTA-A08-8191-1
11
LG4-M1A35-001 CLANK ARM
1 FTA-A08-8192-B
12
LG4-M1A3B-000 HINGE PIN 2
1
FTA-A08-8192-1
13
LG4-M1A36-000 ARM
1
FTA-A08-8193
14
LG4-M1A33-000 LINK PLATE
1
FTA-A08-8194
15
LG4-M1A3L-000 CLANK ARM AXIS PIN
1
FTA-A08-8195
16
LG4-M1A37-000 ADJUST CLAMP PIN
1
FTA-A08-8196
17
LG4-M1A3K-001 CLAMP LEVER AXIS PIN
1 FTA-A08-8197-B
18 LG4-M1A38-000 LINK PIN T
1
FTA-A08-8198
19
LG4-M1A39-000 LINK PIN U
1
FTA-A08-8199
20
LG4-M1ADC-000 SCREW,PAN HEAD+
2
3MC-7-P
21 K87-M111S-000
SCREW,FLAT HEAD+
2
3MK-6-P
22 K87-M111T-000 SCREW,SET 1 3MY-3-F
23 K87-M111X-000 SCREW,SET 1
3MY-4-F
24 K87-M111R-000 SCREW,SET 2
3MY-5-F
25 K87-M111U-000
SCREW FLANGE NUT
2
3MH-FS
26 K87-M21BN-000
SCREW NUT
2
3MH-P
27 K87-M21BM-000 SPRING LOCK WASHER 1
3MU-P
28 K87-M1115-000
CIRCULAR RIVET
1
2-10
29
30
31
32
33
34
