I･pulse　 F1　Series

F1-12 (H type)

P 8

No. Code No. Parts Name Q'ty Parts No.

LG4-M4A9D-001 TENSION LEVER ASSY

1

AS-A12-8181-E

1

LG4-M4A91-012 REEL PLATE

1

FTA-A12-8180-E

2

LG4-M4A9A-002 TENSION LEVER

1

FTA-A12-8181-E

3

LG4-M4A9C-001 GUIDE ARM

1 FTA-A12-8181-E1

4

LG4-M4A92-010 TENSION AXIS

1

FTA-A12-8182-B

5

LG4-M4A9B-001 COIL SPRING

1 FTA-A12-8183-C

6

LG4-M4A93-010 REEL AXIS

1 FTA-A12-8185-C

7 LG4-M4A9E-010

SPACER

1

FTA-A12-8187-C

8

LG4-M4ADE-000

SCREW,FLAT HEAD+ 3 3MK-7-P

9 K87-M55BN-000 SCREW,FLAT HEAD+ 1 3MK-8-P

10 K87-M111U-000 SCREW FLANGE NUT 3 3MH-FS

11

LG4-M4AD4-000 CIRCLIP E

1 E.50

12

LG4-M4AD5-000 FLAT RIVET

2

2×4-2.5-BS

13

LG4-M4ADH-000

SCREW,FLAT HEAD+ 1 4MK-12-P

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

MODEL　　：　F1-12 (H_type)

CODE No. ：　LG4-M4A00-080

Serial No.

F1-12-007958H～
