F1FeederPartsList.pdf - 第12页
1-5
I･pulse F1 Series
F1-82-0603(C type)
No. Code No. Parts Name Q'ty Parts No.
KW1-M1320-000 SPROCKET ASSY 1 AS2-A08-1107-P2
LG4-M1A2A-000 RACKING LEVER ASSY 1 AS -A08-8117-B
LG4-M1A2M-000 RATCHET AXIS ASSY 1 AS -A08-8112
1
K87-M111C-000 PLANE WASHER 1 CTF-A08- 16-B
2
K87-M112B-200 RACKING LEVER 1 CTF-A08- 705-C
3
K87-M112F-000 SPRING HOOK PIN 1 CTF-A08- 211-B2
4
K87-M112M-100 FLANGE A 1 CTF-A08- 712-1
5
KW1-M452D-000 SCREW COIL SPRING 1 CTF-M08- 511-1
6
K87-M1121-000 METAL 1 FTA-A08-1103
7
K87-M1122-000 RIVET 3 FTA-A08-1103-1
8
KW1-M1123-000 SPROCKET 1 FTA-A08-1104-B
9
K87-M1324-000 RATCHET 1 FTA-A08-1107-P2
10
K87-M112G-100 RACKING POLE 1 FTA-A08-1111
11
LG4-M1A2D-000 SHUTTER DRIVE PIN 1 FTA-A08-8109
12
LG4-M1A2C-000 RACKING POLE AXIS 1 FTA-A08-8110
13
LG4-M1A2N-000 RATCHET AXIS 1 FTA-A08-8112
14
LG4-M1A2P-000 FLANGE B 1 FTA-A08-8112-2
15
LG4-M1A2B-000 MAIN ARM 1 FTA-A08-8117-B
16
K87-M11BF-000 SCREW , FLAT HEAD 1 P2MK-4-IB
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
1-4
1-5
I･pulse F1 Series
F1-82-0603(C type)
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A30-010 HOLD LEVER ASSY 1
AS1-A08-8190-B
1 K87-M111G-100 PUSH PIN 1
CTF-M08- 325
2
LG4-M1A1K-000
LEVER AXIS PIN 1
FTA-A08-8130-B
3
LG4-M1A1A-001 COVER PLATE
1
FTA-A08-8149-C
4
LG4-M1AA2-000
SPRING CONNECTOR ASSY
1
FTA-A08-8151-5
5
LG4-M1A31-000 HOLD LEVER M
1 FTA-A08-8190-B
6
LG4-M1A32-000 HOLD LEVER S
1 FTA-A08-8190-1B
7
LG4-M1A34-000 CLAMP LEVER
1 FTA-A08-8191-B
8
LG4-M1A3A-000 HINGE PIN 1
1
FTA-A08-8191-1
9
LG4-M1A35-000 CLANK ARM
1 FTA-A08-8192
10
LG4-M1A3B-000 HINGE PIN 2
1
FTA-A08-8192-1
11
LG4-M1A36-000 ARM
1
FTA-A08-8193
12
LG4-M1A33-000 LINK PLATE
1
FTA-A08-8194
13
LG4-M1A3L-000 CLANK ARM AXIS PIN
1
FTA-A08-8195
14 LG4-M1A37-010
ADJUST CLAMP PIN 1
FTA-A08-8196
15
LG4-M1A3K-000 CLAMP LEVER AXIS PIN
1 FTA-A08-8197
16
LG4-M1A38-000 LINK PIN T
1
FTA-A08-8198
17
LG4-M1A39-000 LINK PIN U
1
FTA-A08-8199
18 LG4-M1ADC-000 SCREW , PAN HEAD ＋ 2 3MC-7-P
19 K87-M111S-000
SCREW , FLAT HEAD ＋
2
3MK-6-P
20 K87-M111T-000 SCREW , SET 1 3MY-3-F
21 K87-M111R-000 SCREW , SET 2
3MY-5-F
22 K87-M111U-000
SCREW FLANGE NUT
2
3MH-FS
23 K87-M21BN-000
SCREW NUT
2
3MH
24 K87-M21BM-000
SPRING LOCK WASHER
1
3MU
25 K87-M1115-000
CIRCULAR RIVET
1
φ2-10
26
27
28
29
30
31
32
33
1-6
