User manual SIPLACE X-Series 6 Component handling
Software Version SR.601.xx 11/2005 US Edition 6.10 Matrix tray changer
367
6
Fig. 6.10 - 3 Matrix tray changer 2, dimensions, all dimensions in
6 Component handling User manual SIPLACE X-Series
6.10 Matrix tray changer Software Version SR.601.xx 11/2005 US Edition
368
6.10.2 Technical data
6.10.2.1 Dimensions, weight, other data
6
*) Waffle tray carrier 6
Tray supply 1 (XL) Tray supply 2
Dimensions
Length x width
Height
1305 x 600 mm²
1490 mm for 830 mm PCB transport height
1560 mm for 900 mm PCB transport height
1590 mm for 930 mm PCB transport height
1610 mm for 950 mm PCB transport height
Weight (basic equipment) Approx. 500 kg (with cassettes and waffle-pack tray carriers)
Weight (fully equipped) Approx. 534 kg (with components)
Weight (moving mass) Approx. 80 kg Approx. 43.5 kg
PCB magazine size (L x W x H) 391.2 x 305.6 x 93.3 mm³ 352.7 x 154.8 x 133.8 mm³
PCB magazine weight
(fully equipped)
(without waffle tray carrier)
Approx. 11 kg
Approx. 1.7 kg
Approx. 7.5 kg
Approx. 1.35 kg
Weight of the waffle tray carrier 850 g 150 g
Dimensions of the waffle tray
carrier (L x W x H) 386.5 x 295.8 x 11.1 mm³ 371 x 146 x 10.1 mm³
Distance from PCB magazine to
magazine
96 mm 135 mm
Distance from level to level 12 mm 11.8 mm
Vertical travel
444 mm (1st to 30th waffle
tray carrier
*
)
511.2 mm (1st to 40th waffle
tray carrier
*
)
Horizontal travel between
outgoing and pick-up position Approx. 647 mm Approx. 638 mm
Storage capacity 30 XL waffle tray carriers with
60 JEDEC or
30 special magazines
of maximum size
40 waffle tray carriers
with 40 JEDEC
waffle trays
Changeover time (over 5 levels) Approx. 2 sec Approx. 1.5 sec
Max. height of component and
waffle tray, including tolerances
all levels filled
one level free
two levels free
8.5 mm
19.5 mm
31.5 mm
8.5 mm
19.5 mm
-
User manual SIPLACE X-Series 6 Component handling
Software Version SR.601.xx 11/2005 US Edition 6.10 Matrix tray changer
369
6.10.2.2 Electrical ratings
6
6.10.2.3 Noise emissions
6
6.10.2.4 Permitted environmental factors
6
Supply voltage
3 x 400 VAC, 50 Hz (Europe)
3 x 208 VAC, 60 Hz (USA)
Total power 1.5 kW
Rated current
2.7 A at 3 x 400 VAC
4.2 A at 3 x 208 VAC
Fuses 3 x 16 A
Rated power consumption of the largest consumer 2 A
Max. noise emissions 74 dB (A)
Room temperature Between 15 °C and 35 °C
Atmospheric humidity
30 - 75 %
(No higher than 45% on average to prevent any
possibility of condensation on the machine)
