(4) Hold down the [POWER ON] button on the operation panel for one second or more. The lamp of the [POWER ON] button illuminates in yellowish green and the self-diagnostics function starts. Fig. 1C8 It takes 2 to 3 minut…
1.2 Preparation before Automatic Operation
1.2.1 Power ON Operation
(1) Ensure the safety around the front safety door and the feeder car-
riage sections.
(2) Remove the padlock from the lock lever of the power breaker.
Fig. 1C6
(3) Set the power breaker to "ON".
Power is supplied to the machine.
To re-power the machine, shut down the main
breaker and wait for about 10 seconds. After that,
turn on the main breaker.
If the main breaker is turned on immediately after it
was shut down, the previous data (the data retained
before the current is intercepted) will not be reset, lead-
ing to a rare malfunction in the breaker.
Fig. 1C7
1.2 Preparation before Automatic Operation
0307-003 3-5 AFO01EOPP
CAUTION
(4) Hold down the [POWER ON] button on the operation panel for one
second or more.
The lamp of the [POWER ON] button illuminates in yellowish green
and the self-diagnostics function starts.
Fig. 1C8
It takes 2 to 3 minutes until the self-diagnostics operation is
completed. Please wait for a while.
When the self-diagnostics operation is completed, "Login Type Selec-
tion" window appears on the touch screen.
Fig. 1C9
(5) Press the [SUPERVISER], the [OPERATOR #1], or the [OPERA-
TOR #2] button according to the given authority. The "Password
Entry" window opens.
Fig. 1C10
219'410
5612
56#46 '0#$.'
4705'672
12'4#6+10
.1%-
20.%*#0)'
1.2 Preparation before Automatic Operation
0307-004 3-6 AFO01EOPP
This machine is provided with a password function which pre-
vents various types of data groups from being deleted by mis-
take and keeps unauthorized user (third party) from operating
the machine.
The following three kinds of passwords are available and each
gives individually approved user’s access to the computer sys-
tem of the machine.
Refer to "Password Setting" in "Section 5 Menus for System
Setting" of "Volume 3: Programming and Machine Data" for de-
tails.
[SUPERVISOR] : Access can be gained by only the person
identified as "Supervisor".
[OPERATOR #1] : Access can be gained by only the person
identified as "Operator #1". For example, the
person identified as "Operator #1" is given
a permission to all machine operations in-
cluding data editing.
[OPERATOR #2] : Access can be gained by only the person
identified as "Operator #2". For example, the
person identified as "Operator #2" is limited
to only the operations related to the auto-
matic operation.
1.2.2 "AUTO OPN." Window and Zeroing of Each Device
(1) Enter the password and press the [Set] button.
The main menu bar appears and the "AUTO OPN." window opens
on the operation screen.
Fig. 1C11
0210-004 3 - 7 AFO01EOPP
1.2 Preparation before Automatic Operation
