2.4 End of "PASS" Operation
2.4.1 Stop of "PASS" Operation
(1) Press the [STOP] button on the front operation panel.
The LED of the [START] button and the green lamp of the light tower
extinguish and the automatic operation stops.
Remove the P.C.B. in the middle of passing inside the machine
if any.
(2) Press the [ALL] button (entitled "ZERO") in the "AUTO OPN." win-
dow. In 2 seconds, press the [ENABLE] button on the operation panel.
2.4.2 Shut-Down Operation
Follow the procedure in "1.7 Shut-Down Operation" and shut down the
power supply.
2.4 End of "PASS" Operation
0207-002 3-27 AFO01EOPP
0207-001 3-28 AFO01EOPP
Section 4
Remedy of Simple Trouble
0307-004 4-A AFO01EOPP
This section describes how to troubleshoot simple problems
that can be solved by the machine operator.
When the operator cannot solve a problem, he/she should
get in contact with the supervisor (a person in charge of
machine management).
