No . W arning Labels and Description *1 or *1-1 *1-2 Description • The labeled sections use high voltage. Do not touch any part of these section to avoid an electric shock. *2 Description • Keep clear of the labeled sect…
Fig. 1X49-1 Component Drop Prevention Cover Section
Fig. 1X49-2 Component Drop Prevention Cover
*19
*22
Bolt Holder
*20
*20
*21
*20
3.1 Warning Label Positions
0301-006 34 AFO01EOPP
No. Warning Labels and Description
*1
or
*1-1
*1-2
Description
• The labeled sections use high voltage.
Do not touch any part of these section to avoid an electric shock.
*2
Description
• Keep clear of the labeled sections because they are activated. Otherwise, part of your
body may be trapped in the moving mechanisms, causing a major injury.
*3
Description
• Before maintenance work (inspections, cleaning, lubrication, or adjustment), turn off
the power and air sources of the machine and follow the specified instruction. Only
qualified personnel should operate the machine carefully.
*4
Description
• Those who wear implanted pacemakers are not allowed to work inside the machine.
Otherwise, the pacemakers may be affected by magnetism, causing a serious acci-
dent.
3.2 Warning Labels and Description
3.2 Warning Labels and Description
Table 1X1
DANGER
DANGER
Cut off power and air sources
during maintenance or inspection.
Electric Shock or Hazardous Area
No maintenance or inspections are allowed
with the machine powered.
WARNING
WARNING
Strong Magnetic Field
Those who wear an implanted pacemaker
are not allowed to work inside the door.
Otherwise, the pacemaker may be affected
by magnetism.
0210-005 35 AFO01EOPP
No. Warning Labels and Description
*5
*6
Description
• Do not operate the machine with the door being kept open. Otherwise, part of your
body may be trapped in the moving mechanisms, causing a major injury.
*7
Description
• Only the trained personnel should operate the machine. Otherwise, a serious accident
such as an electric shock and an injury may not be avoided.
*8
Description
• Before operating the machine, please read the instruction manual carefully for correct
operations.
An operator’s error will break down the machine or a major injury will result.
3.2 Warning Labels and Description
Table 1X2
WARNING
WARNING
Keep the door closed
during operation.
Otherwise, part of your body may be trapped
in the moving mechanisms, causing an injury.
Do not keep the door open during operation.
WARNING
WARNING
Trained Personnel Only!
Electric Shock or Hazardous Area
WARNING
WARNING
Please read the instruction manual
carefully for correct operations
Please read the instruction manual
carefully for correct operations
0210-005 36 AFO01EOPP
