*6 [LOCK] Lamp • While the lamp is ON, it indicates that the selected operation is locked. • When the operation panel is operated from the unavailable side, the [LOCK] lamp flickers. T o cancel the flickering of the lamp…
*3 [STOP] Button
• This button is used to stop the automatic operation.
• When this button is pressed during X/Y table test, the test operation stops.
• When this button is pressed during zeroing operation, the zeroing opera-
tion of each device is interrupted, excluding the P.C.B. transfer.
*4 [ENABLE] Button
• When the [ON] button (entitled "MOVE") is pressed in the active operation
sheet, the lamp of the [ENABLE] button illuminates for two seconds. When
the [ENABLE] button is pressed with its lamp "ON", the machine performs
various operations selected in the operation sheets.
*5 [PNL CHANGE] Button
• This button is used to select either the front or the rear operation panel.
(a) The other operation panel can be selected by pressing the [PNL
CHANGE] button on the unavailable (invalid) side only when
the currently selected panel is not set in the "Operation Locked"
mode.
(b) While the LED of this button is ON, the followings become
available.
Front Touch Screen
[START] Button
[STOP] Button
[ENABLE] Button
[OPERATION] Switch
[EMERGENCY STOP] Switch
Pointing Device
Keyboard
(c) The [STOP] button and [EMERGENCY STOP] switch are al-
ways available regardless of the [PNL CHANGE] button.
(d) When the panel operation is not locked and the [STOP] button
on the unselected operation panel is pressed, the operation
panel on the pressed button side becomes activated automati-
cally.
• When this button is pressed with the LED being "ON", only the front opera-
tion panel becomes available in operations (Operation Locked) and the
[LOCK] lamps on both front and rear operation panels illuminate.
To cancel the "LOCK" mode, press this button again.
2.3 Operational Measures
0307-006 1-13 AFO01EOPP
*6 [LOCK] Lamp
• While the lamp is ON, it indicates that the selected operation is locked.
• When the operation panel is operated from the unavailable side, the [LOCK]
lamp flickers.
To cancel the flickering of the lamp, press the [PNL CHANGE] button and
follow the steps to set the operation-lock mode again.
*7 [OPERATION] Switch
• The selection key must be inserted to change over the [OPERATION] switch
to "RUN" or "SETUP".
The [OPERATION] switch must be set to the "RUN" side for automatic
operation.
The switch can be changed over to "RUN" or "SETUP" only when
the machine is in the "STOP" mode.
• When the switch is changed to the "SETUP" side, the machine is set as
follows.
(a) The red, yellow, and green lamps of the light tower will illuminate (initial
setting of the machine upon shipment).
(b) The following operations are prohibited regardless of the front safety
door condition (opened/closed).
Automatic Operation, P.C.B. Transfer (Cycle) Operation, Zeroing Op-
eration, Device Test, Unit Adjustment, and Teaching Operation
(c) Operations automatically become available on the front operation panel
(operations locked).
No operations are accepted on the rear operation panel.
CAUTION
• When the [OPERATION] switch is set to the
"SETUP" side, the interlock function of the front
safety door is deactivated and it may cause critical
injury to the operator.
• Do not operate the machine with the [OPERATION]
switch in the "SETUP" mode except for the setup
operations.
• Do not keep the selection key inserted unless nec-
essary. The key shall be stored by the person in
charge.
• When the selection key is turned forcibly, the switch
may be damaged.
0307-005 1-14
AFO01EOPP
2.3 Operational Measures
*8 [EMERGENCY STOP] Switch
• This button is used to stop the machine immediately in an emergency.
• When this button is pressed, the power is turned off and the machine stops
immediately.
When the power is turned off, the LED of the [POWER ON] button on the
operation panel illuminates in red.
*9 Keyboard
Fig. 1A12
This keyboard can be used to enter alphanumeric characters in edit
windows for pattern programs and component data.
To enter numerals in one of the windows that belong to "AUTO
OPN." or "MAINT.", the edit window on the screen can be used.
