Checking Items 1. T ransfer and/or Resale of Machine • If the machine is scheduled to be transferred to another place and/or resold to a third party , please contact our marketing department or sales agency beforehand. A…

0307-005 6 AFO01EOPP

Contents

Page

1.2 Preparation before Automatic Operation ................................ 3- 5

1.2.1 Power ON Operation ............................................................... 3- 5

1.2.2 "AUTO OPN." Window and Zeroing of Each Device ....... 3- 7

1.2.3 Preparation for Components and P.C.B.’s ......................... 3- 9

1.3 Start of Automatic Operation ...................................................... 3-11

1.4 Temporary Stop and Restart of Automatic Operation .......... 3-13

1.4.1 Replenishment of Components and P.C.B.’s .................... 3-13

1.4.2 Temporary Stop with [STOP]

or [ON] (entitled "STOP") Button .................................... 3-16

1.4.3 Stop Operation by Selection of

"Auto Stop Mode" ................................................................. 3-16-1

1.5 Interruption of Automatic Operation ......................................... 3-17

1.5.1 Interruption of Automatic Operation

with [CANCEL] Button ......................................................... 3-17

1.5.2 Interruption with [EMERGENCY STOP] Switch ............... 3-17-1

1.6 End of Automatic Operation ........................................................ 3-18

1.6.1 Stop of Automatic Operation ................................................. 3-18

1.7 Shut-Down Operation ................................................................... 3-19

1.7.1 Shut-Down Procedure ............................................................. 3-19

1.7.2 Locking the Power Breaker with the Padlock .................. 3-22

2. "PASS" Mode ....................................................................................... 3-23

2.1 Start of "PASS" Operation ........................................................... 3-23

2.2 Temporary Stop of Pass Operation ........................................... 3-26

2.2.1 Temporary Stop (Pause) with [STOP] Button ................... 3-26

2.3 Interruption of Pass Operation .................................................. 3-26

2.3.1 Interruption with [CANCEL] Button ..................................... 3-26

2.3.2 Interruption with [EMERGENCY STOP] Switch ............... 3-26

2.4 End of "PASS" Operation ............................................................. 3-27

2.4.1 Stop of "PASS" Operation ...................................................... 3-27

2.4.2 Shut-Down Operation .............................................................. 3-27

Section 4 Remedy of Simple Trouble

............................. 4- A

1. Power Operation Impossible........................................................... 4- 1

2. Nothing Displayed on Touch Screen ............................................ 4- 2

3. Remedial Procedure from "ERROR" Window ............................ 4- 3

3.1 [EMERGENCY STOP] Switch Pressed .................................... 4- 3

3.1.1 During Automatic Operation .................................................. 4- 3

3.1.2 During Pass Operation ............................................................ 4- 5-1

3.2 Continuous Operation Disabled during

Component Placement ................................................... 4- 6

Checking Items

1. Transfer and/or Resale of Machine

• If the machine is scheduled to be transferred to another place and/or

resold to a third party, please contact our marketing department or sales

agency beforehand.

Any relocation and/or resale of the machine without prior written notice

or advice, we will in no way be liable for any trouble or malfunctions of

the machine regardless of the possibility of any trouble or malfunctions

arising from the displacement.

• Before setting up a resold and/or transferred machine, please ask our

service personnel or sales agency for safety inspections.

Examples of Errors or Malfunctions after Machine Transfer

(1) The machine may malfunction, depending on the local power

source (difference in power frequency or voltage).

(2) When the machine is transferred to another place, it may mal-

function due to environmental condition such as electric wave

interference or noise.

• These instruction manuals should be regarded as part of the machine.

The contents of these manuals comply with the specifications of the

machine. Whenever the machine is scheduled to be resold to a third

party, be sure to sell the machine together with these manuals.

2. Request on Machine Disposal

• This machine (TCM-X series) uses a strong permanent magnet in the moving

mechanism of the feeder carriage section (F axis).

Before disposing of the machine, please contact our marketing department or

sales agency for the proper disposal.

0301-003 7

AFO01EOPP

Checking Items

3. Modification (Change of Specifications)

Never modify any part of the machine (especially the

main body, the control devices, the safety doors, emer-

gency stop switches, etc.) for functional and safety

purposes.

Do not change the settings of OS (Operating System)

or install any applications additionally.

• Please consult our marketing department or sales agency before chang-

ing the specifications of the machine.

• In no event will we be liable for any direct, special, incidental, or conse-

quential damages resulting from any modification made without any

prior notice to use in a written form.

4. Training

• Only a trained personnel should operate the machine.

Mishandling of the machine will cause a major accident.

• Training of machine operations can be given on the purchaser’s side or

consult our marketing department or sales agency for the detailed in-

formation on training.

5. About Software Applications

• Some software applications of Microsoft Co., Ltd. are used for this ma-

chine.

The attached "COA (Certificate of Authenticity)" and "License Agree-

ment" are issued by Microsoft Co., Ltd. Please read them carefully and

keep them at hand.

Attention: Trade Marks and Registered Trade Marks

• Windows NT is a registered trademark of the Microsoft Corporation in the United

States and other countries.

• All other corporate and product names in this manual are owned by and are the

trademarks or registered trademarks of their respective companies. Neither

(TM) nor (R) marks are described clearly in this manual.

0301-004 8

AFO01EOPP
