Specifications 29-3
29.4 Laser Height Sensor Specifications
Table 29-3 provides laser height sensor specifications for the systems.
Table 29-3 Height Sensor Specifications
Laser Height Sensor
Laser Height Sensor
for Transparent, Reflective Surfaces
Probe Activation Force
NA
NA
Probe Tip Diameter
NA
NA
Probe Retract
NA
NA
Laser Classification
Class 2
Class 2
Light Source
Semiconductor Laser <1 mW,
670 nm (red)
Semiconductor Laser 1 mW,
670 nm (red)
Spot Diameter
700 µm at reference distance of 55 mm
7 µm at reference distance of 30 mm
Reference Distance
and Range
55 mm ± 10 mm
(2.2 in. ± 0.4 in.)
30 mm ± 1 mm
(1.2 in. ± 0.04 in.)
Ambient Light
4,000 lux max.
10,000 lux max.
Sampling Rate
1 kHz
1 kHz
Dynamic Resolution
10 µm
10 µm
Repeatability
± 25 µm @ 3s
(See Note 1)
± 25 µm @ 3s
(See Note 3)
Accuracy
1
± 50 µm @ 3s
± 50 µm @ 3s
Sensing Range
20 mm (± 10 mm)
(see Note 2)
20 mm (± 10 mm)
Operation Mode
Range-finding
Plunge
1
Measured on a white ceramic dispense card (card properties: 96% roll compacted Alumina, flatness 0.003-in. per
linear inch, .8 µm Ra value).
2
Measured from the top of the conveyor rail. The sensing range is 10-mm above and 10-mm below the top of the rail.
If a customer’s height-sense location is 10-mm above the conveyor rail, the LHS will not focus (contact the factory;
a special is required).
3
Measured on a reflective surface.
29-4 Specifications
29.5 Recommended Working Area Allowances
Table 29-4 provides an overall view of the minimum service space allowance for the AXI Systems.
Table 29-4 Working Allowances
Specifications
Front
36 inches
Back
36 inches
Left
Inline: N/A
Batch: 36 inches
Right
Inline: N/A
Batch: 36 inches
Specifications 29-5
29.6 EC Declaration of Conformity
An EC Declaration of Conformity if provided for each system.
Figure 29-1 EC Declaration of Conformity Form
DECLARATION OF CONFORMITY
The machine described below complies with the appropriate basic safety and health
requirements of the listed directives based on its design and type, as delivered by Nordson
YESTECH. In case of alteration of the machine, this declaration may lose its validity.
Application of Council Directive:
Machinery Directive 2006/42/EC and all applicable amendments.
EMC Directive 2004/108/EC and all applicable amendments.
Manufacturer’s Name : Nordson YesTech
Manufacturer’s Address : 2762 Loker Avenue West
Carlsbad, CA 92127 USA
Type of Equipment: Automated X-Ray Inspection (AXI) Systems
Product Series Name: X#
Model Number: X2, X3
Serial Number:
Year of Manufacture:
YesTech’s Contact in EU: “Technical Manager Europe” is
Authorized to compile technical file
YesTech’s Address in EU: Nordson B.V.
Bergerstraat 8
6226 BD Maastricht
The Netherlands
I, the undersigned, hereby declare that the equipment specified above conforms to the
above Directives and Standards.
Signature: ____________________________
Name, President YesTech Date & Place of Issue
