Technical specifi cations 251 Inspection system X7056 | Operating manual | Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a Technical specifications This chapter provides all the im po rtant technical data for the inspecti…
Packing
Disposal
250
Inspection system X7056 | Operating manual |
Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a
Disposal
Disposal of the inspection system must be done according to the
regulations of the land the system is installed in.
Beryllium waste (sealed X-ray tube) must be disposed off as
hazardous waste in special and sealed containers.
It is possible to allow the Viscom AG to properly dispose of the
system. The customer bears the cost of transporting the system to
Viscom.
The Viscom AG observes the regulations established by RoHS-
Directive 2002/95/EC.
Technical specifications 251
Inspection system X7056 | Operating manual |
Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a
Technical specifications
This chapter provides all the important technical data for the
inspection system.
It contains the following technical specifications:
System specifications (Page 252)
Environmental conditions (Page 253)
XM camera technology (Page 254)
Sealed X-ray tube (Page 255)
Flat panel detector (Page 256)
Transport system (Page 257)
System Dimensions (Page 258)
Center of Mass (Page 260)
Tipping Angle (Page 261)
System weight (Page 263)
Technical specifications
System specifications
252
Inspection system X7056 | Operating manual |
Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a
System specifications
This section provides general technical information of the inspec-
tion system.
The following data are presented:
Electrical specifications (Page 252)
Communication interfaces (Page 252)
Noise emission (Page 252)
System computer (Page 252)
Electrical specifications
Communication interfaces
Noise emission
The noise level of the inspection system is under 70 db.
System computer
Electrical specifications
Power supply 230/400 VAC, 50/60 Hz, 3 phase, N, PE
Power supply with internal
transformer for main power
adaptation
190 V - 600 VAC, 50/60 Hz, 3 P/N/PE
Average power consumption 0.78 kW/h
Max. Power 1.5 kW
Min. Power 0.62 kW
Motor overload switch See current circuit diagram
Automatic cutout 8 A characteristic "C"
Communication
Interfaces SMEMA, SV70
Network connection 100 Mbit / 1 Gbit Ethernet
System computer
Operating system Microsoft Windows
®
Processor Intel
®
processor technology
