Appendix

Replacement part lists

267

Inspection system X7056 | Operating manual |

Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a

Replacement part lists

The replacement part lists divide into three different replacement

part packages. Please be sure to use the current index entry for all

article numbers given here!

Basic replacement part package (194.050.B.10)

Part number Name Number

13.012.0215 Inductive sensor 2

77.146.B.07 VTR3 control unit STA 1

77.146.B.05 VTR3 driver II 1

30.008.0138 Sensor interface (VEBI) 1

30.008.0131 Sensor interface (VK2) 1

30.008.0246 Viscom Universal Interface (VUI) 1

11.003.E.08 Step motor 266 1

11.003.E.11 Step motor 268 1

30.008.0147 Viscom Light PWM Control (VLPC) 1

13.008.0075 EMERGENCY STOP module 1

13.008.0067 Contactor 11kW/24VDC 1

13.008.0046 Monitoring relay 1

13.006.0041 Switched-mode power supply 24V 200W 1

13.006.0093 Switched-mode power supply 24V 320W 1

13.006.0073 Switched-mode power supply 48V 500W 1

194.104.B.04 Guide pulley transport 2

180.102.B.07 Guide pulley transport 2

20.016.0237 Timing belt 14AT5 1

20.016.0216 Timing belt 14-AT5-420 1

20.016.0223 Gear belt, width AOI 1

20.016.0225 Gear belt, width AXI 1

20.016.0224 Gear belt, clamping AOI 1

20.016.0222 Gear belt, clamping AXI 1

13.008.0036 Auxiliary switching block LADN22 10A 1

13.013.0057 Fan grid 120x120 4

13.013.0092 Filter mat Poret PPI 30 2

Extended replacement part package (194.050.B.07)

Part number Name Number

30.008.0148 Viscom Router (VR12) 1

30.008.0122 Viscom Input Module (VIM) 1

Appendix

Replacement part lists

268

Inspection system X7056 | Operating manual |

Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a

30.008.0123 Viscom Output Module (VOM) 1

160.101.B.14 Adapter box for encoder 1

11.009.0048 Measurement head AOI-X 1

11.009.0052 Measurement head AXI-X 1

11.009.0047 Measurement head AOI-Y 1

11.009.0048 Measurement head AXI-Y 1

11.009.0074 Axis controller Ecovario 1

194.105.0015 Spindle, clamping AOI 1

20.005.0395 Spindle, clamping AXI 1

20.005.0348 Linear bearing, clamping AOI/AXI 1

194.104.B.11 Ball screw drive, clamping AOI / AXI 1

194.104.B.12 Drive set, clamping belt AOI 1

20.005.0388 Linear bearing, register drive AOI 2

20.005.0393 Linear bearing, register drive AXI 1

20.005.0392 Spindle, register drive AOI 1

20.005.0389 Spindle, register drive AXI 1

194.105.B.06 Drive set, register AOI 2

194.104.B.41 Drive set, register AXI 2

194.104.B.31 Drive set, register AXI 2

194.104.B.30 Drive set, lift frame AOI /AXI 2

20.005.0130 Guide carriage AOI-X/Y + AXI-Y 2

20.005.0023 Guide carriage AXI-X 2

20.005.0269 Guide carriage AXI-X plate 2

13.019.0024 Linear encoder 1

13.013.0057 Fan grid 120x120 4

13.013.0092 Filter mat Poret PPI 30 2

30.008.0210 AND module 24 V 1

12.002.0425 VEB-101 camera multiplexer 1

Replacement part package, wearing parts (194.050.B.08)

Part number Name Number

13.004.0030 Fuse 1A delayed-action 1

13.004.0007 Fuse 4A delayed-action 3

13.004.0095 Fuse 5A delayed-action 1

13.004.0024 Fuse 6.3A delayed-action 1

Extended replacement part package (194.050.B.07) (Forts.)

Part number Name Number

Appendix

Replacement part lists

269

Inspection system X7056 | Operating manual |

Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a

13.004.0054 Fuse 2A fast-acting 1

13.004.0027 Fuse 4A fast-acting 2

13.010.0001 Lamp, X-ray front 1

13.010.0002 Bulb, X-ray signal lamp 1

194.105.0108 Belts, AOI transport 2

194.104.0162 Belts, AXI transport 2

20.005.0385 Linear bearing, lift frame AOI / AXI 1

194.105.0061 Stop rubber, PCB stopper 2

13.016.0697 Fuse 250V/800mA F 1

13.016.1263 Fuse, miniature, 0.75 A,T 1

13.016.1200 Fuse, miniature, Series MSB 1

Replacement part package, wearing parts (194.050.B.08) (Forts.)

Part number Name Number
