Appendix Replacement parts list, 3-D opt ion 274 Inspection system X7056 | Operating manual | Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a Replacement parts list, 3-D option Please be sure to use the curr ent index ent…

100%1 / 280
Appendix
Replacement parts list, flat panel detector (FPD)
273
Inspection system X7056 | Operating manual |
Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a
35.791.0200 Y-data cable 2xM8 3pol 1
35.710.0220 Control cable 3x2AWG28+2AWG28 1
35.707.0220 Control cable 5xAWG20 sh 1
Replacement part package, positioning unit (194.050.B.19) with FPD 1520
Part number Name Number
20.016.0282 Toothed belt 16 AT5 /450 PAZ-AS 1
20.016.0281 Toothed belt 10 AT5-330-PAZ-AS 1
13.012.0305 Sensor IND IFFM 08P17A6/L 1
20.005.0269 Runner Block Standard 15 2
13.006.0142 Switched-mode power supply HRP 75-24 1
13.006.0127 Switched-mode power supply RSP 320-24
320 W / 24 V
1
13.006.0130 Switched-mode power supply RSP-320-27 1
13.016.1311 ELKO 10000µF/100V 1
11.009.0141 ECOMiniDual 007DG-BN-000-000 1
11.009.E.24 Motor 23S41-0650-805N7-55 1
32.011.0100 Sensor IND IFFM 08P17A6/L 1
32.011.0030 Sensor IND IFFM 08P17A6/L 1
35.780.0300 Data cable 4x2x0.14 1
35.787.0400 Supply cable 2x0.34 1
35.780.0250 Data cable 4x2x0.14 1
35.775.0500 Data cable 2x0.34 1
35.710.0220 Control cable 3x2AWG28+2AWG28 1
35.707.0220 Control cable 5xAWG20 sh 1
Replacement part package, positioning unit (194.050.B.17) with FPD 1548
Part number Name Number
Appendix
Replacement parts list, 3-D option
274
Inspection system X7056 | Operating manual |
Version 3.1 Rev.006| 2016-01-06 | 30.009.1930a
Replacement parts list, 3-D option
Please be sure to use the current index entry for all article
numbers given here!
Replacement part package, 3-D option (194.050.B.15)
Part number Name Number
35.655.0740 Power supply cable 1
126.235.B.05 LED retainer 1
