AHB01EOPP (4) Hold down the [POWER ON] button on the operation panel for more than 1 second. The lamp of the [POWER ON] button illuminates in red and the self- diagnostics function starts. Fig. 1C7 It takes 2 to 3 minute…
AHB01EOPP
(3) Set the power breaker to "ON".
Power is supplied to the machine.
To re-power the machine, shut down the main breaker
and wait for about 10 seconds. After that, turn on the
main breaker.
If the main breaker is turned on immediately after it
was shut down, the previous data (the data retained
before the current is intercepted) will not be reset, lead-
ing to a rare malfunction in the breaker.
Fig. 1C6
1.2 Preparation before Operation
CAUTION
0308-001 3-5-1
AHB01EOPP
(4) Hold down the [POWER ON] button on the operation panel for more
than 1 second.
The lamp of the [POWER ON] button illuminates in red and the self-
diagnostics function starts.
Fig. 1C7
It takes 2 to 3 minutes until the self-diagnostics operation is
completed. Please wait for a while.
When the self-diagnostics operation is completed, the lamp of the
[POWER ON] button changes in yellow and "Login Type Selection" win-
dow appears on the touch screen.
Fig. 1C8
1.2 Preparation before Operation
Note
0308-003 3-6
MULTI FUNCTIONAL MOUNTER
STOP
LOCK
OPERATION
RUN SETUP
START
ENABLE
PNL CHANGE
READY
POWER ON
EMERGENCY
AHB01EOPP
(5) Press the [SUPERVISER], the [OPERATOR #1], or the [OPERA-
TOR #2] button according to the given authority.
The "Password Entry" window opens.
When a password is already set, the "Password Entry" window
opens.
Fig. 1C9
This machine is provided with a password function which pre-
vents various types of data groups from being deleted by mis-
take and keeps unauthorized user (third party) from operating
the machine.
The following three kinds of passwords are available and each
gives individually approved user’s access to the computer sys-
tem of the machine.
Refer to "4.2 "Password" Tab" in "Section 5" of "Vol. 3: Pro-
gramming and Machine Data" for details.
[SUPERVISOR] : Access can be gained by only the person
identified as "Supervisor".
[OPERATOR #1] : Access can be gained by only the person
identified as "Operator #1". For example, the
person identified as "Operator #1" is given
a permission to all machine operations in-
cluding data editing.
[OPERATOR #2] : Access can be gained by only the person
identified as "Operator #2".
For example, the person identified as "Op-
erator #2" is limited to only the operations
related to the automatic operation.
1.2 Preparation before Operation
Note
0206-003 3 - 7
