• When the tower light (green) is ON or flickering, it shows that the static
machine is in the "automatic" mode (awaiting mode).
• When there is a problem with the machine, locate the cause and assess
the condition. After the problem has been rectified, turn off power supply
(if required) and follow reset procedures.
Refer to "Vol. 4: Maintenance and Troubleshooting" for details.
• Ensure personnel (part of body and clothes) and foreign objects remain
clear of the moving parts of the machine.
• Keep your face and hands away from any moving parts of the machine
during operation.
Fig. 1X12
2.3 Precautionary Items during Operation
0308-003 1 5 AHB01EOPP
WARNING
WARNING
CAUTION
Fig. 1X13
• When the machine stops due to a component pick-up error, be sure to
remove the mispicked component from the tape feeder and then start
the automatic operation.
Tape Feeder
Vibratory Stick Feeder
2.3 Precautionary Items during Operation
0308-004 1 6 AHB01EOPP
CAUTION
Fig. 1X14
Fig. 1X14-1
2.4 Precautionary Measures before Maintenance Work
Air Source Section
• Before maintenance work, be sure to lock the power breaker and
the main valve section (air source) with padlocks.
Power Breaker : Set the power breaker to the "OFF" side and lock
it with a padlock.
Air Source : Stop the air supply, set the main valve to the
"EXH." side, and lock the valve with a padlock.
• Designate a person who can have charge of the padlock key.
• If the provided padlock is lost or damaged, purchase its substi-
tute.
Power Supply Section
2.4 Precautionary Measures before Maintenance Work
• Only qualified personnel should perform maintenance work carefully in
compliance with the specified procedures.
0308-003 1 7
AHB01EOPP
Padlock
(630 061 9737)
Main Valve
WARNING
WARNING
Fig. 1X15
Fig. 1X16
