0308-003 1 1 AHB01EOPP • Only a well-trained personnel should operate the machine. • In case of earthquake, windstorm, fire, or lightning, stop the machine im- mediately , turn off power switches and cut the power supply…

0308-004 1 0 AHB01EOPP

2. Safety Requirements

Refer to "2.1 Basic Precautions", "2.2 Precautionary Items before Op-

eration", "2.3 Precautionary Items during Operation", "2.4 Precaution-

ary Measures before Maintenance Work", and "2.5 Pre-Installation

Checks" for details.

2.1 Basic Precautions

2. Safety Requirements

• The machine must be used with the covers being attached.

Each cover is provided to protect people and objects from any injuries

and damages that might be caused by any moving and high-voltage

areas.

Confirm that no covers are disengaged before operating the machine.

Otherwise, be sure to attach them in place.

• Never modify any part of the machine such as the [EMERGENCY

STOP] switches, the front and rear safety doors, etc.

Fig. 1X9

Fig. 1X8

Front Safety Door

Front Side of Machine Rear Side of Machine

Rear Safety Door

[EMERGENCY STOP] Switch

[EMERGENCY

STOP] Switch

DANGER

WARNING

0308-003 11 AHB01EOPP

• Only a well-trained personnel should operate the machine.

• In case of earthquake, windstorm, fire, or lightning, stop the machine im-

mediately, turn off power switches and cut the power supply to the ma-

chine.

2.1 Basic Precautions

• Do not use the floppy disk drive in the control box. Otherwise, the ma-

chine may break down because the program in the hard disk of the ma-

chine may be changed due to computer viruses or worms.

Fig. 1X9-1 Floppy Disk Drive in Control Box

WARNING

CAUTION

2.2 Precautionary Items before Operation

• Remove the selection key of the [OPERATION] switch before

operating the machine automatically.

The selection key must be used to set the [OPERATION] switch to the

"SETUP" mode and kept by the person in charge. In other cases, the key

should not be kept inserted.

• Do not set the [OPERATION] switch to the "SETUP" side un-

less any setup operations are performed.

When the [OPERATION] switch is set to the "SETUP" side, setup opera-

tions become possible with the front safety door being open. It is very

dangerous to operate the machine without safety check. Be sure to pay

a special caution while operating the machine.

Fig. 1X10

• Make certain that no one (or only part of body and clothes) or foreign

objects remain within the moving parts of the machine. Check safety

and power up the machine to start operating the machine.

Do not start the machine unless those working in the immedi-

ate area of the machine are aware of hazards from moving parts.

0308-003 1 2 AHB01EOPP

RUN SETUP

Front Operation Panel

OPERATION

[OPERATION] Switch

Selection Key

WARNING
