2.3.4 Status Indicator Fig. 1A10-1 The status indicator (green lamp) is used to indicate how the tape feed- ers are replenished with component supply . Lamp ON/OFF Condition T able 1A2-2 Mode Condition of Feeder Base ON …
2.3.3 Component Shortage Lamps
Fig. 1A10
When either one of the component shortage lamps illuminate, it indi-
cates that there is a feeder in short of components on the pertinent
feeder base.
The front component shortage lamp indicates the condition of the feed-
ers on the front feeder bases (#3 and #4).
The rear component shortage lamp indicates the condition of the feed-
ers on the rear feeder bases (Feeder Base #1 and Tray #2).
When the machine is equipped with Feeder Base #2 (op-
tion),
the rear component shortage lamp indicates the condition of
the feeders on the rear feeder bases (#1 and #2).
Lamp ON/OFF Condition
Table 1A3
Mode Condition of Feeder Base
ON No tape feeder is in component shortage.
ON and OFF A tape feeder is in component shortage.
OFF There is no tape feeder which can be used
in the current pattern program.
When the "Component Shortage" lamp flickers, replenish the compo-
nent supply.
Refer to "1.4.1 Replenishment of Components" in "Section 3"
for the detailed information on the replenishment of components.
0206-003 1-11 AHB01EOPP
2.3 Equipment for Operations
Note
Note
2.3.4 Status Indicator
Fig. 1A10-1
The status indicator (green lamp) is used to indicate how the tape feed-
ers are replenished with component supply.
Lamp ON/OFF Condition
Table 1A2-2
Mode Condition of Feeder Base
ON Loaded with Components
(Replenishment Completed)
ON and OFF Not Loaded with Components
(Component Shortage)
OFF Not used in the current pattern program
When the status indicator flickers, replenish the component supply.
(a) Refer to "1.4.1 Replenishment of Components" in "Sec-
tion 3" for the detailed information on the replenishment of
components.
(b) The status indicator flickers (indicating component short-
age) according to the parameter specified in the "1" text
box of the label "Error process" in the component library
data.
0206-001 1-1 1-1
AHB01EOPP
Status Indicator
2.3 Equipment for Operations
Note
2.3.5 [TRAY LOAD] Switch (Option)
Fig. 1A10-2
The [TRAY LOAD] switch (green lamp) is used to indicate how the multi-
layer tray feeder (option) is replenished with component supply.
Lamp ON/OFF Condition
Table 1A2-3
Mode Condition of Multi-Layer Tray Feeder
ON Loaded with Components
(Replenishment Completed)
ON and OFF Not Loaded with Components
(Component Shortage)
OFF Not used in the current pattern program
When the [TRAY LOAD] switch flickers, replenish the component sup-
ply.
(a) Refer to the instruction manual "Multi-Layer Tray Feeder
(TIM-X Series)" for the replenishment of tray components.
(b) The [TRAY LOAD] switch flickers (indicating component
shortage) according to the parameters specified in the
"Matrix X" and "Matrix Y" text boxes of the label "Tray data"
or the "1" text box of the label "Error process" in the com-
ponent library data.
2.3 Equipment for Operations
0308-002 1-1 1-2 AHB01EOPP
[TRAY LOAD] Switch
