1.Safety Guideline SYS-CP842-1.1E
4 CP-842E / CP-842ME System Reference
1.2 Safety Rules for All Machine Types
DANGER
Do not approach moving parts during automatic or manual
operation.
• Do not place hands or other body parts inside the machine
during automatic operation or positioning. Body parts or
clothing may be caught in the machine causing personal
injury.
Do not operate the machine with the safety covers or doors
open.
• Do not leave covers or safety doors open, except during
adjustment.
• When adjustments are completed, return the covers and doors
to their original (closed) position.
• When safety covers or doors are removed, body parts or
clothing may be caught in the machine causing personal
injury. Always be sure to replace the safety covers or doors.
WARNING
Always verify the position of the EMERGENCY STOP
buttons before operating the machine.
• Always be aware of the positions of the EMERGENCY STOP
buttons so that they can be pressed quickly in case of an
emergency.
Check the safety functions before starting operation.
• Before starting the machine check the operation of the
EMERGENCY STOP button, the safety switches on the
acrylic covers, the safety switch on the rear fence gate, the
optical sensors on the rear fence and all other machine safety
features.
• Contact a Fuji serviceman immediately if any of the safety
functions fails.
SYS-CP842-1.1E 1.Safety Guideline
CP-842E / CP-842ME System Reference 5
Do not remove safety switches.
• Do not remove safety switches or disarm the safety functions.
• Disarming the safety switches may result in injury when others
unknowingly press the START button.
• Fuji does not take any responsibility when a machine is
disassembled without Fuji's permission, even if this results in
accidents or trouble.
Check that there is nobody inside the machine when
working on the machine with two persons or more.
• Verify that nobody is within or near the machine before
operating the machine. Operating the machine may cause
injury to the person who is carrying out maintenance.
• [Example]
If one person moves the device table while another person is
exchanging a feeder, the latter may be injured.
Do not approach a machine that has stopped moving.
• There are times during automatic operation when the machine
may appear to have stopped while it is waiting for a board,
waiting for the next machine, reading marks, transmitting data,
etc. In such cases, once certain conditions are fulfilled, the
machine will begin moving again automatically, so care should
be taken. Only approach the machine after the EMERGENCY
STOP button has been pressed. When the message "Ready"
displays at the machine display, the machine will begin to
move once certain conditions are satisfied.
• Keep in mind that the machine will begin to move regardless
of whether these conditions are satisfied intentionally or
inadvertently.
Resupply solder paste, glue and parts while the machine is
in manual mode.
• Never resupply solder, glue or parts during automatic
operation unless instructed otherwise. Body parts or clothing
may be caught in the machine causing personal injury.
Do not place hands near the main conveyor.
• Hands or other body parts may be caught in the machine.
WARNING
1.Safety Guideline SYS-CP842-1.1E
6 CP-842E / CP-842ME System Reference
Always turn the 200 V power supply off when cleaning or
lubricating the machine.
• When the 200 V power supply to the machine is turned on, the
servo amps will be activated. In this condition the machine
may unexpectedly begin to move.
Do not insert or remove connectors while power is being
supplied to the machine.
• Removing or inserting connectors while power is supplied to
the machine may not only cause damage to the machine, but
may also cause electrical shock.
Stay clear from the machine when it is being lifted.
• Never put hands or feet under the machine when the machine
is being raised by means of a jack or other device for leveling
or transport.
Do not wear gloves made of cloth when operating the
machine.
• Rubber gloves will tear when caught by the machine and
prevent hands from being drawn into the machine. Gloves
made of cotton or similarly strong material may cause hands
to be drawn into the machine.
Long hair should be tied back.
• Long hair may get caught in running machines.
• Hair should be kept short or tied back so that it does not get
caught in the machine.
Turn off the air supply when carrying out maintenance on
cylinders, valves, and filters.
• Removing cylinders, valves, or filters without turning the air
supply off, may cause parts or particles to be propelled into
the eyes.
• Be sure to turn off the air supply when carrying out
maintenance on cylinders, valves, and filters.
Be sure to wear protective glasses when removing parts
from the machine.
• Be sure to wear protective glasses when removing or
replacing parts.
WARNING
