SYS-CP842-1.1E 5.I/O Map CP-842E / CP-842ME System Reference 197 5.1.2 Standard Output Signals Output-1 Address Signal Name Description Y000 START SWITCH LAMP ON1 Sid e1 Start switch lamp on Y001 READY ON1 LAMP ON Side1 …
5.I/O Map SYS-CP842-1.1E
196 CP-842E / CP-842ME System Reference
X0D9 OUT-CARRIER FORWARD
LIMIT UNCLAMP CHK
(ADJUSTABLE RAIL)
Out-carrier advance end unclamp
(Adjustable rail)
Carrier opened: O
X0DA XY TABLE OUTSIDE LOADING
POSITION CHECK
XY-table loading position
(outside)
Loading position: O
X0DB ADJUSTING RAIL
ENGAGEMENT CHECK (OUT)
Adjusting rail engagement
(outside)
Rail clutching: O
X0DC ADJUSTING RAIL
ENGAGEMENT CHECK
(CENTER)
Adjusting rail engagement
(center)
Rail clutching: O
X0DD Not used
X0DE Not used
X0DF RESERVED Reserved
Addre
ss
Signal Name Description Signal Status at I/O
Screen
SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 197
5.1.2 Standard Output Signals
Output-1
Address Signal Name Description
Y000 START SWITCH LAMP ON1 Side1 Start switch lamp on
Y001 READY ON1 LAMP ON Side1 Ready on lamp on
Y002 BUZZER ON1 Side1 Buzzer on
Y003 Not used
Y004 SIGNAL TOWER RED ON Signal tower (red lamp)
Y005 SIGNAL TOWER YELLOW ON Signal tower (yellow lamp)
Y006 SIGNAL TOWER BLUE ON Signal tower (blue lamp)
Y007 SIGNAL TOWER RED BLINK Signal tower (red flash)
Y008 SIGNAL TOWER YELLOW BLINK Signal tower (yellow flash)
Y009 SIGNAL TOWER BLUE BLINK Signal tower (blue flash)
Y00A START SWITCH LAMP ON2 Side2 Start switch lamp on
Y00B READY ON2 LAMP ON Side2 Ready on lamp on
Y00C BUZZER ON2 Side2 Buzzer on
Y00D Side2 ENABLE Side 2 Enable
Y00E CAM AXIS ABS SETUP Cam-axis ABS setup
Y00F TIME COUNTER ON Time counter on
Y010 MASTER ON Master on
Y011 OVERTRAVEL CUT Cut overtravel control
Y012 FRONT DOOR LOCK Front door lock
Y013 REAR DOOR D1 LOCK Rear door D1 lock
Y014 REAR DOOR MIDDLE LOCK Rear door middle lock
Y015 REAR DOOR D2 LOCK Rear door D2 lock
Y016 SHUTDOWN Shutdown
Y017 FIDUCIAL LAMP ON Fiducial lamp on
Y018 PANEL REQUEST Panel request signal from previous stage
Y019 BOARD AVAILABLE Panel available signal to next stage
Y01A FOLLOW PERMIT OUTPUT Permit follow up (HELPS)
Y01B X AXIS ABS SETUP X-axis ABS setup
Y01C Y AXIS ABS SETUP Y-axis ABS setup
5.I/O Map SYS-CP842-1.1E
198 CP-842E / CP-842ME System Reference
Y01D Z AXIS ABS SETUP Z-axis ABS setup
Y01E PQ AXIS ABS SETUP PQ-axis ABS setup
Y01F FQ AXIS ABS SETUP FQ-axis ABS setup
Y020 FRONTLIGHT 1 ON Frontlight 1 on
Y021 FRONTLIGHT 2 ON Frontlight 2 on
Y022 VACUUM BACKUP Vacuum backup
Y023 MAIN-LIFTER MIDDLE OT INVALID Main-lifter middle overtravel invalid
Y024 Not used
Y025 Not used
Y026 VACUUM PUMP ON Vacuum pump on
Y027 RING BLOW ON Ring blow on
Y028 OIL COOLER ON Oil cooler on
Y029 IN-CONVEYOR MOTOR ON In-conveyor motor on
Y02A IN-CONVEYOR MOTOR REVERSE ON In-conveyor motor reverse on
Y02B IN-CONVEYOR MOTOR REDUCE ON In-conveyor motor reduce speed
Y02C Not used
Y02D OUT-CONVEYOR MOTOR ON Out-conveyor motor on
Y02E CONVEYOR WIDTH MOTOR ON Conveyor width motor on (HELPS)
Y02F CONVEYOR WIDTH MOTOR
REVERSE ON
Conveyor width reverse motor on
(HELPS)
Y030 ST1 PICKUP SOL DISENGAGED Stn1 Pickup Solenoid off
Y031 ST1 PICKUP SOL ENGAGED Stn1 Pickup Solenoid on
Y032 ST1 TAPE FEED SOL DISENGAGED Stn1 tape feed solenoid off
Y033 ST1 TAPE FEED SOL ENGAGED Stn1 tape feed solenoid on
Y034 ST9 PLACE SOL DISENGAGED Stn9 placing solenoid off
Y035 ST9 PLACE SOL ENGAGED Stn9 placing solenoid on
Y036 ST14 NOZZLE CHANGE SOL
DISENGAGED
Stn14 nozzle switch solenoid off
Y037 ST14 NOZZLE CHANGE SOL
ENGAGED
Stn14 nozzle switch solenoid on
Y038 Not used
Y039 Not used
Y03A ST9 (ST13) AIR BLOW ON Stn9 (Stn13) Air blow on
Address Signal Name Description
