SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 163
Hard Disk Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Hard Disk]
Press to read operator settings from, and copy operator settings to the hard disk.
Revision history:
Holder Center Nozzle Check
Command Path: [Nozzle Check] - [Holder Center]
Press to select holder center as an item for nozzle measurement.
Revision history:
Host Command bar (All Screens)
Command Path: [Host]
Press to display a dialog box for selection of the communication and control statuses.
Revision history:
Idle Operation
Command Path: [Operation] - [Idle]
Press to set the production mode to Idle.
Revision history:
Ignore Operation
Command Path: [Operation] - [Ignore]
Press to operate the machine without reading skip marks.
Revision history:
Image Buffer Vision system
Command Path: [Maintenance] - [Vision System] - [Image Buffer]
Press to access the screen at which the images stored in the image buffer can be
viewed.
Revision history:
4.Commands SYS-CP842-1.1E
164 CP-842E / CP-842ME System Reference
Immediate Recovery
Command Path: [Recovery] - [Immediate]
Press to set the recovery action to Immediate.
Revision history:
In-carrier Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [In-carrier Pick-up]
Press to load the panel on the in-lifter to the in-carrier. Press the START button to
execute.
Revision history:
In-side Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [In-side]
Press to select the panel loading side of the machine as the target for subsequent
loader commands.
Revision history:
I/O Check Maintenance
Command Path: [Maintenance] - [I/O Check]
Press to access the screen at which system or servo related I/Os can be selected.
Revision history:
Jog Command bar (All Screens)
Command Path: [Jog]
Press to display a dialog box where inching speeds can be set for each of the axis
groups.
Revision history:
Joint Operation
Command Path: [Operation] - [Joint]
Press to set the device table mode to Joint.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 165
Joint Resupply Operation
Command Path: [Operation] - [Joint Resupply]
Press to set the device table mode to Joint Resupply.
Revision history:
Left to Right Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Loader] - [Left to Right]
Press to select panel conveyance from left to right.
Revision history:
Lifter Down Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Lifter Down]
Press to lower the lifter at the selected side of the machine. Press the START button
to execute.
Revision history:
Lifter Up Panel Loader
Command Path: [Panel Loader] - [Lifter Up]
Press to raise the main conveyor. Press the START button to execute the operation.
This command is only operative when the XY-table is at the loading and unloading
positions.
Revision history:
Lifter Up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Lifter Up]
Press to raise the lifter at the selected side of the machine. Press the START button to
execute.
Revision history:
