4.Commands SYS-CP842-1.1E
178 CP-842E / CP-842ME System Reference
Recovery Main
Command Path: [Recovery]
Press to access the screen at which recovery related settings can be made.
Revision history:
Reinspect Image Buffer
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Reinspect]
Press to reinspect the image that is stored in the image buffer.
Revision history:
Remaining Panels Board Skip
Command Path: [Board Skip Data] - [Remaining Panels]
Press to enable board skip settings for all remaining panels.
Revision history:
Restore Program Data Manager
Command Path: [Maintenance] - [Data Manager] - [Restore Program]
Press to display the screen at which programs can be restored.
Revision history:
Restore System Data Manager
Command Path: [Maintenance] - [Data Manager] - [Restore System]
Press to display the screen at which the system settings can be restored.
Revision history:
Results Trace Settings
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Results]
Press for a graphical display of the inspection results.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 179
Right to Left Loader
Command Path: [Maintenance] - [Configuration] - [Loader] - [Right to Left]
Press to select panel conveyance from right to left.
Revision history:
Save Operator Data Manager
Command Path: [Maintenance] - [Operator] - [Data Manager] - [Save]
Press to display the screen at which operator settings can be output.
Revision history:
Servo I/O Check
Command Path: [Maintenance] - [I/O check] - [Servo]
Press to access the screen at which servo related I/O checks can be performed.
Revision history:
Servo Coordinates Position
Command Path: [Position] - [Servo Coordinates]
Press to display the numeric keypad for specification of the coordinates to which the
selected axis (selected at the commands [X-axis] and [Y-axis]) will be moved.
Revision history:
Servo Count Command bar (All Screens)
Command Path: [Servo Count]
Press to display a dialog box where the servo counts for all axis can be viewed in
pulses or mm/degree.
Revision history:
Servo Setup Maintenance
Command Path: [Maintenance] - [Servo Setup]
Press to display the screen at which the servos can be checked.
Revision history:
4.Commands SYS-CP842-1.1E
180 CP-842E / CP-842ME System Reference
Set Ignore After Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Set Ignore
After]
Press to display the keyboard at which the Ignore after comment can be set. Any
characters that appear after the selected comment are ignored by the Handy Termi-
nal.
Revision history:
Set Ignore Between Handy Terminal
Command Path: [Maintenance] - [Configuration] - [Handy Terminal] - [Set Ignore
Between]
Press to display the keyboard at which the Ignore between comment can be set. Any
characters that are enclosed by the selected comment are ignored by the Handy Termi-
nal.
Revision history:
Signal Tower Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Signal Tower]
Press to access the screen at which the signal tower settings can be specified.
Revision history:
Standard I/O check
Command Path: [Maintenance] - [I/O check] - [Standard]
Press to access the screen at which a standard I/O check can be performed.
Revision history:
Start Sequence Production
Command Path: [Production] - [Start Sequence]
Press to display the Numeric Keypad and input the starting sequence.
Revision history:
