SYS-CP842-1.1E 4.Commands CP-842E / CP-842ME System Reference 153 Board Skip Data Main Command Path: [Board Skip Data] Press to access the boar d skip setting screen. Revision history: Board Skip Dat a Production Command…
4.Commands SYS-CP842-1.1E
152 CP-842E / CP-842ME System Reference
Command name Screen name
Actuator Maintenance
Command Path: [Maintenance] - [Actuator]
Press to access a diagnostics screen for the machine actuators.
Revision history:
Automatic Production
Command Path: [Production]
Press to set the production mode to Automatic.
Revision history:
Auto Conveyor Change Machine Configuration Data
Command Path: [Maintenance] - [Machine Configuration Data] - [Auto Conveyor
Change]
Press to access the screen at which settings can be made for conveyor width change
during changeover operation.
Revision history:
Auto Recovery Recovery
Command Path: [Recovery] - [Auto Recovery]
Press to execute automatic recovery in response to part errors.
Revision history:
Basic Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Basic]
Press to access the screen at which the basic machine calibration settings can be
made.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 153
Board Skip Data Main
Command Path: [Board Skip Data]
Press to access the board skip setting screen.
Revision history:
Board Skip Data Production
Command Path: [Production] - START button - [Board Skip Data]
Press to change the display during production to board skip related information.
Revision history:
Board Skip Settings Machine Configuration Data
Command Path: [Maintenance] - [Configuration] - [Board Skip Settings]
Press to access the screen at which settings can be made for machine operation after
the detection of board skip marks.
Revision history:
Brightness Nozzle Check
Command Path: [Nozzle Check] - [Brightness]
Press to specify brightness as one of the nozzle check inspection items.
Revision history:
Brightness Deviation Nozzle Check Limits
Command Path: [Nozzle Check] - [Nozzle Check Limits] - [Brightness Deviation]
Press to edit the brightness standard deviation tolerance level.
Revision history:
Calibration Maintenance
Command Path: [Maintenance] - [Calibration]
Press to access the screen at which the commands related to machine calibration can
be selected.
Revision history:
4.Commands SYS-CP842-1.1E
154 CP-842E / CP-842ME System Reference
Calibration Data System Backup
Command Path: [Maintenance] - [Data Manager] - [System Backup] - [Calibration
Data]
Press to select calibration data for backup.
Revision history:
Calibration Editor Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Calibration Editor]
Press to access the screen at which machine calibration data items can be edited.
Revision history:
Caliper Trace Settings
Command path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Caliper]
Press to display caliper information.
Revision history:
Carrier Clamp Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Clamp]
Press to clamp the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
Carrier Extend Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Carrier Extend]
Press to advance the carrier at the selected side of the machine. Press the START but-
ton to execute.
Revision history:
