SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 167
Loading Pos Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Loading Pos]
Press to access the screen at which the panel loading positions can be set in calibra-
tion data.
Revision history:
Load Panel Panel Loader
Command Path: [Panel Loader] - [Load Panel]
Press to unload the panel currently on the main conveyor, and load a new panel to the
main conveyor.
Press the START button to execute the operation.
Revision history:
Load Two Panels Panel Loader
Command Path: [Panel Loader] - [Load Two Panel]
Press to unload the panel currently on the main conveyor, and load two new panels to
the main conveyor.
Press the START button to execute the operation.
Revision history:
Machine Recovery
Command Path: [Recovery] - [Machine]
Press to use the recovery limit setting at the machine.
Revision history:
Machine Configuration System Backup
Command Path: [Maintenance] - [Data Manager] - [System Backup] - [Machine Con-
figuration]
Press to select machine configuration data for backup.
Revision history:
4.Commands SYS-CP842-1.1E
168 CP-842E / CP-842ME System Reference
Main Conveyor Pick-up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Main Conveyor Pick-up]
Press to load the panel on the in-carrier to the main conveyor. Press the START but-
ton to execute.
Revision history:
Maintenance Main
Command Path: [Maintenance]
Press to access the screen at which maintenance related commands can be selected.
Revision history:
Mark Camera Resolution Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Mark Camera Resolution]
Press to access the screen at which the mark camera resolution can be measured.
Revision history:
Mark Editor Production
Command Path: [Production] - [Mark Editor]
Press to access the screen at which fiducial marks can be edited.
Revision history:
Mid-stopper Down Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Mid-stopper Down]
Press to lower the mid-stopper at the selected side of the machine. Press the START
button to execute.
Revision history:
Mid-stopper Pos. Conveyor Width
Command Path: [Conveyor] - [Mid-stopper Pos.]
Press to display the screen at which the mid-stopper position can be specified.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 169
Mid-stopper Up Loader Maintenance
Command Path: [Panel Loader] - [Loader Maintenance] - [Mid-stopper Up]
Press to raise the mid-stopper at the selected side of the machine. Press the START
button to execute after confirming that panels are not positioned above the stopper.
Revision history:
Move to Loading Position Panel Loader
Command Path: [Panel Loader] - [Move to Loading Position]
Press to move the main conveyor to the panel loading position.
Press the START button to execute the operation.
Revision history:
Move to Unloading Position Panel Loader
Command Path: [Panel Loader] - [Move to Unloading Position]
Press to move the main conveyor to the panel unloading position.
Press the START button to execute the operation.
Revision history:
Narrow Camera Nozzle Check
Command Path: [Nozzle Check] - [Narrow Camera]
Press to display the results for the narrow camera.
Revision history:
Network System
Command Path: [Maintenance] - [System] - [Network]
Press to access the screen at which network related settings can be made.
Revision history:
