4.Commands SYS-CP842-1.1E
176 CP-842E / CP-842ME System Reference
Pick-up Miss Basic Configuration
Command Path: [Maintenance] - [Configuration] - [Basic] - [Pick-up Miss]
Press to perform a changeover to the next device when a parts out condition or a
pickup error occurs.
Revision history:
Pick-up pos Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Pick-up Pos]
Press to access the screen at which the pick-up reference positions can be set.
Revision history:
Pick-up Reference Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Pick-up Reference]
Press to access the Pickup Reference Position Setting screen.
Revision history:
Place Reference Machine Calibration Data
Command Path: [Maintenance] - [Calibration] - [Place Reference]
Press to access the screen at which the placing position can be set in calibration data.
Revision history:
Position Main
Command Path: [Position]
Press to access the screen at which positioning commands can be selected.
Revision history:
Production Main
Command Path: [Production]
Press to access the screen at which automatic operation can be executed.
Revision history:
SYS-CP842-1.1E 4.Commands
CP-842E / CP-842ME System Reference 177
Production Operation
Command Path: [Operation] - [Production]
Press to set the operation mode to Production.
Revision history:
Program Main
Command Path: [Program]
Press to access the screen at which program related settings can be made.
Revision history:
Program Backup Data Manager
Command Path: [Maintenance] - [Data Manager] - [Program Backup]
Press to access the screen at which programs can be backed up.
Revision history:
Program Coordinates Position
Command Path: [Position] - [Program Coordinates]
Press to display the numeric keypad for specification of the coordinates to which the
selected axis (selected at the commands [X-axis] and [Y-axis]) will be moved.
Revision history:
Program Editor Maintenance
Command Path: [Maintenance] - [Program Editor]
Press to access the screen at which program related settings can be made.
Revision history:
Read Operation
Command Path: [Operation] - [Read]
Press to enable the detection of skip marks.
Revision history:
4.Commands SYS-CP842-1.1E
178 CP-842E / CP-842ME System Reference
Recovery Main
Command Path: [Recovery]
Press to access the screen at which recovery related settings can be made.
Revision history:
Reinspect Image Buffer
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Reinspect]
Press to reinspect the image that is stored in the image buffer.
Revision history:
Remaining Panels Board Skip
Command Path: [Board Skip Data] - [Remaining Panels]
Press to enable board skip settings for all remaining panels.
Revision history:
Restore Program Data Manager
Command Path: [Maintenance] - [Data Manager] - [Restore Program]
Press to display the screen at which programs can be restored.
Revision history:
Restore System Data Manager
Command Path: [Maintenance] - [Data Manager] - [Restore System]
Press to display the screen at which the system settings can be restored.
Revision history:
Results Trace Settings
Command Path: [Maintenance] - [Vision System] - [Image Buffer] - [Trace Settings] -
[Results]
Press for a graphical display of the inspection results.
Revision history:
