SYS-CP842-1.1E 5.I/O Map CP-842E / CP-842ME System Reference 199 Ouput-2 Y03B Not used Y03C Not used Y03D SIDE 2 LOCK LAMP ON Side2 Fix operation lamp on Y03E N FEED TIMES TAPE CUT CYLINDER Number of tape cut operations …
5.I/O Map SYS-CP842-1.1E
198 CP-842E / CP-842ME System Reference
Y01D Z AXIS ABS SETUP Z-axis ABS setup
Y01E PQ AXIS ABS SETUP PQ-axis ABS setup
Y01F FQ AXIS ABS SETUP FQ-axis ABS setup
Y020 FRONTLIGHT 1 ON Frontlight 1 on
Y021 FRONTLIGHT 2 ON Frontlight 2 on
Y022 VACUUM BACKUP Vacuum backup
Y023 MAIN-LIFTER MIDDLE OT INVALID Main-lifter middle overtravel invalid
Y024 Not used
Y025 Not used
Y026 VACUUM PUMP ON Vacuum pump on
Y027 RING BLOW ON Ring blow on
Y028 OIL COOLER ON Oil cooler on
Y029 IN-CONVEYOR MOTOR ON In-conveyor motor on
Y02A IN-CONVEYOR MOTOR REVERSE ON In-conveyor motor reverse on
Y02B IN-CONVEYOR MOTOR REDUCE ON In-conveyor motor reduce speed
Y02C Not used
Y02D OUT-CONVEYOR MOTOR ON Out-conveyor motor on
Y02E CONVEYOR WIDTH MOTOR ON Conveyor width motor on (HELPS)
Y02F CONVEYOR WIDTH MOTOR
REVERSE ON
Conveyor width reverse motor on
(HELPS)
Y030 ST1 PICKUP SOL DISENGAGED Stn1 Pickup Solenoid off
Y031 ST1 PICKUP SOL ENGAGED Stn1 Pickup Solenoid on
Y032 ST1 TAPE FEED SOL DISENGAGED Stn1 tape feed solenoid off
Y033 ST1 TAPE FEED SOL ENGAGED Stn1 tape feed solenoid on
Y034 ST9 PLACE SOL DISENGAGED Stn9 placing solenoid off
Y035 ST9 PLACE SOL ENGAGED Stn9 placing solenoid on
Y036 ST14 NOZZLE CHANGE SOL
DISENGAGED
Stn14 nozzle switch solenoid off
Y037 ST14 NOZZLE CHANGE SOL
ENGAGED
Stn14 nozzle switch solenoid on
Y038 Not used
Y039 Not used
Y03A ST9 (ST13) AIR BLOW ON Stn9 (Stn13) Air blow on
Address Signal Name Description
SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 199
Ouput-2
Y03B Not used
Y03C Not used
Y03D SIDE 2 LOCK LAMP ON Side2 Fix operation lamp on
Y03E N FEED TIMES TAPE CUT CYLINDER Number of tape cut operations (n)
Y03F SEQUENCE DATA RECEIVED
REPORT (D1)
Sequence data received report (D1)
Y040 N FEED TIMES FEEDER CYLINDER Number of tape feed operations (n)
Y041 Not used
Y042 FOREIGN MATTER DETECT ORDER Foreign matter presence inspection
Y043 XY-TABLE PANEL CLAMP (FIXED
RAIL)
XY-table panel clamp (fixed rail)
Y044 XY-TABLE PANEL UNCLAMP (FIXED
RAIL)
XY-table panel unclamp (fixed rail)
Y045 XY-TABLE PANEL CLAMP
(ADJUSTABLE RAIL)
XY-table panel clamp (adjustable rail)
Y046 XY-TABLE PANEL UNCLAMP
(ADJUSTABLE RAIL)
XY-table panel unclamp (adjustable rail)
Y047 MCID CONVEYOR MOTOR ON MCID conveyor motor on
Y048 MCID CONVEYOR MOTOR REDUCE
ON
MCID conveyor motor speed reduce
Y049 MCID CONVEYOR MOTOR REVERSE
ON
MCID conveyor motor reverse on
Y04A MCID CONVEYOR WIDTH MOTOR ON MCID conveyor width motor on
Y04B MCID CONVEYOR WIDTH MOTOR
REVERSE ON
MCID conveyor width motor reverse on
Y04C MCID RAISE IN-CONVEYOR
STOPPER
MCID in-conveyor stopper up
Y04D MCID RAISE IN-REVERSE
CONVEYOR STOPPER
MCID in-reverse conveyor stopper up
Y04E BC LAMP 1 Barcode reader lamp 1
Y04F BC LAMP 2 Barcode reader lamp 2
Address Signal Name Description
Y050 SIGNAL TOWER YELLOW ON 1 Signal tower (Yellow lamp 1)
Y051 SIGNAL TOWER YELLOW BLINK 1 Signal tower (Yellow blink 1)
Y052 D1 PCU CLAMP (1) D1 Pallet change unit clamp 1
Address Signal Name Description
5.I/O Map SYS-CP842-1.1E
200 CP-842E / CP-842ME System Reference
Y053 D1 PCU UNCLAMP (1) D1 Pallet change unit unclamp 1
Y054 D1 PCU CLAMP (2) D1 Pallet change unit clamp 2
Y055 D1 PCU UNCLAMP (2) D1 Pallet change unit unclamp 2
Y056 D1 PALLET UP Raise D1 pallet
Y057 D1 PALLET DOWN Lower D1 pallet
Y058 D1 TABLE STOPPER CLAMP D1 table stopper clamp
Y059 D1 TABLE STOPPER UNCLAMP D1 table stopper unclamp
Y05A Not used
Y05B Not used
Y05C Not used
Y05D Not used
Y05E ACQ.FEEDER ID Acquire feeder ID
Y05F SIDE1 LOCK LAMP ON Side 1 Fix operation lamp on
Y060 SIGNAL TOWER YELLOW ON 2 Signal tower (Yellow lamp 2)
Y061 SIGNAL TOWER YELLOW BLINK 2 Signal tower (Yellow blink 2)
Y062 D2 PCU CLAMP (1) D2 Pallet change unit clamp 1
Y063 D2 PCU UNCLAMP (1) D2 Pallet change unit unclamp 1
Y064 D2 PCU CLAMP (2) D2 Pallet change unit clamp 2
Y065 D2 PCU UNCLAMP (2) D2 Pallet change unit unclamp 2
Y066 D2 PALLET UP Raise D2 pallet
Y067 D2 PALLET DOWN Lower D2 pallet
Y068 D2 TABLE STOPPER CLAMP D2 table stopper clamp
Y069 D2 TABLE STOPPER UNCLAMP D2 table stopper unclamp
Y06A Not used
Y06B Not used
Y06C Not used
Y06D Not used
Y06E Not used
Y06F SEQUENCE DATA RECEIVED
REPORT (D2)
Sequencer data received report (D2)
Y070 RAISE IN-CONVEYOR 2ND PANEL
STOPPER
Raise in-conveyor 2nd panel stopper
Address Signal Name Description
