5.I/O Map SYS-CP842-1.1E
194 CP-842E / CP-842ME System Reference
X0B5 IN-LIFTER UPPER LIMIT
CHECK
In-lifter upper end Upper limit: O
X0B6 IN-LIFTER LOWER LIMIT
CHECK
In-lifter lower limit Lower limit: O
X0B7 IN-CARRIER RETRACT LIMIT
CLAMP CHECK (FIXED RAIL)
In-carrier retract end clamp
(Fixed rail)
Carrier closed: O
X0B8 IN-CARRIER RETRACT LIMIT
CLAMP CHECK (ADJUSTABLE
RAIL)
In-carrier retract end clamp
(Adjustable rail)
Carrier closed: O
X0B9 IN-CARRIER FORWARD LIMIT
CLAMP CHECK (FIXED RAIL)
In-carrier advance end clamp
(Fixed rail)
Carrier closed: O
X0BA IN-CARRIER FORWARD LIMIT
CLAMP CHECK (ADJUSTABLE
RAIL)
In-carrier advance end clamp
(Adjustable rail)
Carrier closed: O
X0BB IN-CARRIER RETRACT LIMIT
UNCLAMP (FIXED RAIL)
In-carrier retract end unclamp
(Fixed rail)
Carrier opened: O
X0BC IN-CARRIER RETRACT LIMIT
UNCLAMP CHECK
(ADJUSTABLE RAIL)
In-carrier retract end unclamp
(Adjustable rail)
Carrier opened: O
X0BD IN-CARRIER FORWARD LIMIT
UNCLAMP CHECK (FIXED
RAIL)
In-carrier advance end unclamp
(Fixed rail)
Carrier opened: O
X0BE IN-CARRIER FORWARD LIMIT
UNCLAMP CHECK
(ADJUSTABLE RAIL)
In-carrier advance end unclamp
(Adjustable rail)
Carrier opened: O
X0BF XY-TABLE INSIDE LOADING
POSITION CHECK
XY-table loading position (inside) Loading position: O
X0C0 ADJUSTING RAIL
ENGAGEMENT CHECK (IN)
Adjusting rail engagement
(inside)
Rail clutching: O
X0C1 IN-CONVEYOR 1ST PANEL
STOPPER UPPER LIMIT
CHECK
In-conveyor 1st panel stopper
upper limit
Stopper raised: O
X0C2 IN-CONVEYOR 1ST PANEL
STOPPER LOWER LIMIT
CHECK
In-conveyor 1st panel stopper
lower limit
Stopper lowered: O
X0C3 THERMO FUSE OK Thermo fuse OK Normal: O
X0C4 OUT-CONVEYOR 2ND PANEL
STOPPER UPPER LIMIT
CHECK
Out-conveyor 2nd panel stopper
upper limit
Stopper raised: O
X0C5 OUT-CONVEYOR 2ND PANEL
STOPPER LOWER LIMIT
CHECK
Out-conveyor 2nd panel stopper
lower limit
Stopper lowered: O
X0C6 Not used
Addre
ss
Signal Name Description Signal Status at I/O
Screen
SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 195
X0C7 OUT-CONVEYOR 1 PANEL
ARRIVAL CHECK
Out-conveyor 1 panel arrival Panel present: O
X0C8 Not used
X0C9 OUT-CONVEYOR 2 PANEL
ARRIVAL CHECK
Out-conveyor 2 panel arrival Panel present: O
X0CA PANEL INTERVAL BETWEEN
OUT-CONVEYOR 1 AND 2
Panel interval between out-
conveyor 1 and 2
Panel present: X
X0CB OUT-CONVEYOR UNLOADER
PANEL ARRIVAL CHECK
Out-conveyor unloader panel
arrival
Panel present: O
X0CC OUT-CARRIER FORWARD
LIMIT PANEL CHECK (1)
Out-carrier advance end panel
check 1
Panel present: O
X0CD OUT-CARRIER FORWARD
LIMIT PANEL CHECK (2)
Out-carrier advance end panel
check 2
Panel present: O
X0CE OUT-CARRIER FORWARD
LIMIT CHECK
Out-carrier advance end Advanced limit: O
X0CF OUT-CARRIER RETRACTED
LIMIT CHECK
Out-carrier retract end Retracted limit: O
X0D0 OUT-LIFTER UPPER LIMIT
CHECK
Out-lifter upper limit Upper limit: O
X0D1 OUT-LIFTER LOWER LIMIT
CHECK
Out-lifter lower limit Lower limit: O
X0D2 OUT-CARRIER RETRACT LIMIT
CLAMP CHECK (FIXED RAIL)
Out-carrier retract end clamp
(Fixed rail)
Carrier closed: O
X0D3 OUT-CARRIER RETRACT LIMIT
CLAMP CHECK (ADJUSTABLE
RAIL)
Out-carrier retract end clamp
(Adjustable rail)
Carrier closed: O
X0D4 OUT-CARRIER FORWARD
LIMIT CLAMP CHECK (FIXED
RAIL)
Out-carrier advance end clamp
(Fixed rail)
Carrier closed: O
X0D5 OUT-CARRIER FORWARD
LIMIT CLAMP CHECK
(ADJUSTABLE RAIL)
Out-carrier advance end clamp
(Adjustable rail)
Carrier closed: O
X0D6 OUT-CARRIER RETRACT LIMIT
UNCLAMP CHECK (FIXED
RAIL)
Out-carrier retract end unclamp
(Fixed rail)
Carrier opened: O
X0D7 OUT-CARRIER RETRACT LIMIT
UNCLAMP CHK (ADJUSTABLE
RAIL)
Out-carrier retract end unclamp
(Adjustable rail)
Carrier opened: O
X0D8 OUT-CARRIER FORWARD
LIMIT UNCLAMP CHECK
(FIXED RAIL)
Out-carrier advance end unclamp
(Fixed rail)
Carrier opened: O
Addre
ss
Signal Name Description Signal Status at I/O
Screen
5.I/O Map SYS-CP842-1.1E
196 CP-842E / CP-842ME System Reference
X0D9 OUT-CARRIER FORWARD
LIMIT UNCLAMP CHK
(ADJUSTABLE RAIL)
Out-carrier advance end unclamp
(Adjustable rail)
Carrier opened: O
X0DA XY TABLE OUTSIDE LOADING
POSITION CHECK
XY-table loading position
(outside)
Loading position: O
X0DB ADJUSTING RAIL
ENGAGEMENT CHECK (OUT)
Adjusting rail engagement
(outside)
Rail clutching: O
X0DC ADJUSTING RAIL
ENGAGEMENT CHECK
(CENTER)
Adjusting rail engagement
(center)
Rail clutching: O
X0DD Not used
X0DE Not used
X0DF RESERVED Reserved
Addre
ss
Signal Name Description Signal Status at I/O
Screen
