SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 187
X02E D2 AXIS ABS SETUP
COMPLETE
D2-axis ABS setup complete Setup complete: O
X02F NZ AXIS ABS SETUP
COMPLETE
NZ-axis ABS setup complete Setup complete: O
X030 ST1 NOZZLE UPPER LIMIT
CHECK
Stn1 Nozzle Upper limit Upper limit: O
X031 CAM AXIS FAN ALARM Cam-axis fan alarm Error: X
X032 ST9 NOZZLE UPPER LIMIT
CHECK
Stn 9 Nozzle Upper limit Upper limit: O
X033 ST9 NOZZLE LOWER LIMIT
CHECK
Stn 9 Nozzle Lower limit Lower limit: O
X034 Not used
X035 Not used
X036 ST2 LARGE PART CHECK Stn 2 large parts check Parts present: O
X037 D1 PARTS SET COMPLETE D1 parts set complete Parts set complete:
O
X038 D1 PARTS SET CANCEL D2 parts set cancel Parts set cleared: O
X039 ST10 NOZZLE CLUTCH ORIGIN
POSITION
Stn 10 Nozzle clutch origin
position
Origin position: O
X03A ST10 NOZZLE CLUTCH
ENGAGEMANT CHECK
Stn 10 Nozzle clutch engagement Clutching: X
X03B FEEDING FORWARD LIMIT Stn1 Feeding lever advance end Dog engaged: O
X03C FEEDING RETRACT LIMIT Stn1 Feeding lever retract end Dog engaged: O
X03D TAPE END CHECK Tape end detection No tape: O
X03E ST13 NOZZLE TYPE CHECK1 Stn13 Nozzle type check 1 Nozzle detected: O
X03F ST13 NOZZLE TYPE CHECK2 Stn13 Nozzle type check 2 Nozzle detected: O
X040 ST13 NOZZLE TYPE CHECK3 Stn13 Nozzle type check 3 Nozzle detected: O
X041 XY-TABLE PANEL CHECK XY-table panel presence Panel present: O
X042 ST1 FEEDER CHECK Stn1 feeder check Tape guide up:5
X043 D1 FEEDER CHECK UP D1 Feeder check (Up) Feeder up: X
X044 D1 FEEDER CHECK DOWN D1 Feeder check (Down) Feeder up: X
X045 MAINTENANCE MODE ON Maintenance Mode ON Maintenance Mode
ON: O
X046 PARTS HEIGHT
MEASUREMENT READY
SIGNAL
Parts height measurement ready
Addre
ss
Signal Name Description Signal Status at I/O
Screen
5.I/O Map SYS-CP842-1.1E
188 CP-842E / CP-842ME System Reference
X047 FOREIGN MATTER WARNING Foreign matter presence warning
X048 ST15 NOZZLE TYPE CHECK1 Stn15 Nozzle type check 1 Nozzle detected: O
X049 ST15 NOZZLE TYPE CHECK2 Stn15 Nozzle type check 2 Nozzle detected: O
X04A ST15 NOZZLE TYPE CHECK3 Stn15 Nozzle type check 3 Nozzle detected: O
X04B Not used
X04C Not used
X04D TAPECUTTER UPPER LIMIT Tapecutter Upper limit Upper limit: O
X04E TAPECUTTER LOWER LIMIT Tapecutter Lower limit Lower limit: O
X04F ST11 HEAD A CHECK Stn11 Head A check Dog engaged: O
Addre
ss
Signal Name Description Signal Status at I/O
Screen
SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 189
Input-2
Addre
ss
Signal Name Description Signal Status at I/O
Screen
X050 OIL COOLER UNIT OK Oil cooler unit OK Error: X
X051 OIL CIRCULATION
CONFIRMATION
Oil circulation confirmation Error: X
X052 CAM TIMING CHANGE CHECK Cam timing change check HDS (high density
specification)
compatible
machine: O
X053 CAM HANDLE SWITCH Cam handle switch Handle engaged: O
X054 D2 FEEDER CHECK UP D2 Feeder check (Up) Raised feeder: X
X055 D2 FEEDER CHECK DOWN D2 Feeder check (Down) Raised feeder: X
X056 PANEL AVAILABLE SIGNAL Panel available signal to next
stage
Panel available: O
X057 PANEL REQUEST Panel request signal to preceding
stage
Panel request: O
X058 FOLLOW PERMIT INPUT Follow up permit Follow permit: O
X059 XY-TABLE REFERENCE PIN
INSERTION CHECK
XY-table reference pin insertion Insertion error: X
X05A XY-TABLE PANEL CLAMP
RAISED CLAW CHECK
XY-table panel clamp raised claw Raised claw: X
X05B VACUUM OK Vacuum pressure check switch Error: X
X05C XY-TABLE LOADING HEIGHT
CHECK
XY-table loading height Lifter raised: O
X05D PANEL THICKNESS CHECK
SENSOR
Panel thickness check
X05E MAIN-LIFTER MIDDLE OT Main-lifter middle overtravel Dog engaged: X
X05F XY-TABLE PANEL CLAMP
CHECK (FIXED RAIL RIGHT)
XY-table panel clamp
(Fixed rail right)
Clamped: O
X060 XY-TABLE PANEL CLAMP
CHECK (ADJUSTABLE RAIL
RIGHT)
XY-table panel clamp
(Adjustable rail right)
Clamped: O
X061 XY-TABLE PANEL UNCLAMP
CHECK (FIXED RAIL RIGHT)
XY-table panel unclamp
(Fixed rail right)
Unclamped: O
X062 XY-TABLE PANEL UNCLAMP
CHECK (ADJUSTABLE RAIL
RIGHT)
XY-table panel unclamp
(Adjustable rail right)
Unclamped: O
X063 XY-TABLE PANEL CLAMP
CHECK
(FIXED RAIL LEFT)
XY-table panel clamp
(Fixed rail left)
Clamped: O
