5.I/O Map SYS-CP842-1.1E 200 CP-842E / CP-842ME System Reference Y053 D1 PCU UNCLAMP (1) D1 Pallet change unit unclamp 1 Y054 D1 PCU CLAMP (2) D1 Pallet change unit clamp 2 Y055 D1 PCU UNCLAMP (2) D1 Pallet change unit u…
SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 199
Ouput-2
Y03B Not used
Y03C Not used
Y03D SIDE 2 LOCK LAMP ON Side2 Fix operation lamp on
Y03E N FEED TIMES TAPE CUT CYLINDER Number of tape cut operations (n)
Y03F SEQUENCE DATA RECEIVED
REPORT (D1)
Sequence data received report (D1)
Y040 N FEED TIMES FEEDER CYLINDER Number of tape feed operations (n)
Y041 Not used
Y042 FOREIGN MATTER DETECT ORDER Foreign matter presence inspection
Y043 XY-TABLE PANEL CLAMP (FIXED
RAIL)
XY-table panel clamp (fixed rail)
Y044 XY-TABLE PANEL UNCLAMP (FIXED
RAIL)
XY-table panel unclamp (fixed rail)
Y045 XY-TABLE PANEL CLAMP
(ADJUSTABLE RAIL)
XY-table panel clamp (adjustable rail)
Y046 XY-TABLE PANEL UNCLAMP
(ADJUSTABLE RAIL)
XY-table panel unclamp (adjustable rail)
Y047 MCID CONVEYOR MOTOR ON MCID conveyor motor on
Y048 MCID CONVEYOR MOTOR REDUCE
ON
MCID conveyor motor speed reduce
Y049 MCID CONVEYOR MOTOR REVERSE
ON
MCID conveyor motor reverse on
Y04A MCID CONVEYOR WIDTH MOTOR ON MCID conveyor width motor on
Y04B MCID CONVEYOR WIDTH MOTOR
REVERSE ON
MCID conveyor width motor reverse on
Y04C MCID RAISE IN-CONVEYOR
STOPPER
MCID in-conveyor stopper up
Y04D MCID RAISE IN-REVERSE
CONVEYOR STOPPER
MCID in-reverse conveyor stopper up
Y04E BC LAMP 1 Barcode reader lamp 1
Y04F BC LAMP 2 Barcode reader lamp 2
Address Signal Name Description
Y050 SIGNAL TOWER YELLOW ON 1 Signal tower (Yellow lamp 1)
Y051 SIGNAL TOWER YELLOW BLINK 1 Signal tower (Yellow blink 1)
Y052 D1 PCU CLAMP (1) D1 Pallet change unit clamp 1
Address Signal Name Description
5.I/O Map SYS-CP842-1.1E
200 CP-842E / CP-842ME System Reference
Y053 D1 PCU UNCLAMP (1) D1 Pallet change unit unclamp 1
Y054 D1 PCU CLAMP (2) D1 Pallet change unit clamp 2
Y055 D1 PCU UNCLAMP (2) D1 Pallet change unit unclamp 2
Y056 D1 PALLET UP Raise D1 pallet
Y057 D1 PALLET DOWN Lower D1 pallet
Y058 D1 TABLE STOPPER CLAMP D1 table stopper clamp
Y059 D1 TABLE STOPPER UNCLAMP D1 table stopper unclamp
Y05A Not used
Y05B Not used
Y05C Not used
Y05D Not used
Y05E ACQ.FEEDER ID Acquire feeder ID
Y05F SIDE1 LOCK LAMP ON Side 1 Fix operation lamp on
Y060 SIGNAL TOWER YELLOW ON 2 Signal tower (Yellow lamp 2)
Y061 SIGNAL TOWER YELLOW BLINK 2 Signal tower (Yellow blink 2)
Y062 D2 PCU CLAMP (1) D2 Pallet change unit clamp 1
Y063 D2 PCU UNCLAMP (1) D2 Pallet change unit unclamp 1
Y064 D2 PCU CLAMP (2) D2 Pallet change unit clamp 2
Y065 D2 PCU UNCLAMP (2) D2 Pallet change unit unclamp 2
Y066 D2 PALLET UP Raise D2 pallet
Y067 D2 PALLET DOWN Lower D2 pallet
Y068 D2 TABLE STOPPER CLAMP D2 table stopper clamp
Y069 D2 TABLE STOPPER UNCLAMP D2 table stopper unclamp
Y06A Not used
Y06B Not used
Y06C Not used
Y06D Not used
Y06E Not used
Y06F SEQUENCE DATA RECEIVED
REPORT (D2)
Sequencer data received report (D2)
Y070 RAISE IN-CONVEYOR 2ND PANEL
STOPPER
Raise in-conveyor 2nd panel stopper
Address Signal Name Description
SYS-CP842-1.1E 5.I/O Map
CP-842E / CP-842ME System Reference 201
Y071 LOWER IN-CONVEYOR 2ND PANEL
STOPPER
Lower in-conveyor 2nd panel stopper
Y072 IN-CARRIER PANEL CLAMP In-carrier panel clamp
Y073 IN-CARRIER PANEL UNCLAMP In-carrier panel unclamp
Y074 IN-CARRIER ADVANCED In-carrier advance
Y075 IN-CARRIER RETRACTED In-carrier retract
Y076 IN-LIFTER UP In-lifter up
Y077 IN-LIFTER DOWN In-lifter down
Y078 RAISE IN-CONVEYOR STOPPER Raise in-conveyor stopper
Y079 LOWER IN-CONVEYOR STOPPER Lower in-conveyor stopper
Y07A Not used
Y07B Not used
Y07C PARTS HEIGHT IMAGE CHANGE 1 Parts height image change 1
Y07D PARTS HEIGHT IMAGE CHANGE 2 Parts height image change 2
Y07E UV LIGHT ON UV light ON
Y07F MARK CAMERA H-LIGHT ON (BLUE) Mark camera horizontal light ON (Blue)
Y080 RAISE OUT-CONVEYOR 2ND PANEL
STOPPER
Raise out-conveyor 2nd panel stopper
Y081 LOWER OUT-CONVEYOR 2ND PANEL
STOPPER
Lower out-conveyor 2nd panel stopper
Y082 OUT-CARRIER PANEL CLAMP Out-carrier panel clamp
Y083 OUT-CARRIER PANEL UNCLAMP Out-carrier panel unclamp
Y084 OUT-CARRIER ADVANCED Out-carrier advance
Y085 OUT-CARRIER RETRACTED Out-carrier retract
Y086 OUT-LIFTER UP Out-lifter up
Y087 OUT-LIFTER DOWN Out-lifter down
Y088 Not used
Y089 Not used
Y08A MARK CAMERA H-LIGHT ON (RED) Mark camera horizontal light ON (Red)
Y08B MARK CAMERA V-LIGHT ON (BLUE) Mark camera vertical light ON (Blue)
Y08C MARK CAMERA V-LIGHT ON (RED) Mark camera vertical light ON (Red)
Y08D Not used
Y08E VERIFICATION OK BUZZER Verification OK buzzer
Address Signal Name Description
