FlexTRAK Series 2MB Material Handler Addendum Parts Replacement B-6 © 2023 Nordson C orporation I tem De scription 2 E-ASSY, STEPR DRIVER, 3. 5A Figure B-3 2M B MH Conve yor Motor Cabinet 2
FlexTRAK Series 2MB Material Handler Addendum Parts Replacement
© 2023 Nordson Corporation B-5
B.7.1 FlexTRAK-2MB Electrical System
Item
Description
Item
Description
2
FRU, POWER SUPPLY, 48VDC,
320W (PS12)
2
ETHERNET MODULE, DL205,
PROGRAMMED
2
FRU, POWER SUPPLY, 24VDC,
320W (PS11)
2 DIGITAL INPUT MODULE, 32 POINT
2 CONTROLLER, PCON-C-42 2 MODULE, STEPPER CARD, H2-CTR10
2
CONTROLR, POSIT, 56FRAME,
NPN, 24V
12 SIO TERMINAL BLOCK
10 PWA, INTERFACE, 2MB
Figure B-2 2MB MH Electrical Cabinet
1
2
1
0
2
2
2
2
2
2
2
2
2
2
FlexTRAK Series 2MB Material Handler Addendum Parts Replacement
B-6 © 2023 Nordson Corporation
I
tem
De
scription
2 E-ASSY, STEPR DRIVER, 3.5A
Figure B-3 2MB MH Conveyor Motor Cabinet
2
FlexTRAK Series 2MB Material Handler Addendum Parts Replacement
© 2023 Nordson Corporation B-7
B.7.2 2MB Shuttler System
Item
D
escription
Item
Description
13 GAUGE,2IN DIAL1/4NPT,1-100PSI 16 VLV, 5PRT, 3POS, CLSD CNTR, 24VDC
2 SWITCH, PRESSURE, 62PSI, INCR 2 VALVE, SOLENOID, 3PORT, 24VDC
14 REGULTR, DIALSET, 160PSI, 1/4"NPT 15 GAUGE, 2IN DIAL1/4NPT, 1-60
2 SWITCH, PRESSURE, 42PSI, DECR
Figure B-4 2MB Shuttler System
1
3
1
4
2
1
5
1
4
1
6
2
2
