FlexTRAK Series 2MB Material Handler Addendum Installation
© 2023 Nordson Corporation 3-3
3.4 Unpacking and Storing the System
3.4.1 Unpacking the System
WARNING! Crated equipment should be moved with a forklift to reduce the
potential for injury.
CAUTION! Many system components are heavy. Use proper lifting and
moving procedures to avoid serious injury.
When the FlexTRAK-2MB System arrives at your facility, we recommend that you perform the
following procedure to ensure it has arrived in good condition.
To unpack the system:
1. Before opening the shipping crate, visually inspect it for damage.
„ Make note of any damage found and immediately report it to the shipping company.
2. Carefully remove the shipping crate and all interior and exterior packaging material.
Visually inspect the main plasma unit and all other system components for any damage.
„ Immediately report any damage found to Technical Support.
„ Keep all shipping containers and materials in case it should be necessary to return any
item to Nordson.
3. Using the included packing list, check to ensure that all listed components have arrived at
your facility.
„ Immediately report any missing or damaged items to Technical Support.
?
NOTE Claims based on late notification of shipping damage will be denied.
FlexTRAK Series 2MB Material Handler Addendum Installation
3-4 © 2023 Nordson Corporation
3.4.2
33B33B
Storing the System
If the FlexTRAK-2MB System is to be placed in long-term storage, place all system components in
protective packaging. A desiccant should be placed in the packaging to minimize moisture exposure.
Store components in a room with humidity of less than 80 percent.
To pack for long-term storage:
1. Fill the pump reservoir with oil to the proper level.
2. Run the pump for five minutes to lubricate the seals.
3. Remove all water from the cooling system.
4. Purge all gas lines and the chamber.
DANGER! Certain process gases or liquids selected for use with this
equipment can cause fire or explosion. Do not expose equipment
to any ignition sources. Consult your safety officer and the
manufacturer’s SDS to ensure proper precautionary steps are
taken.
WARNING! Certain process gases selected for use with this equipment are
toxic and require special precautions. Consult your safety
officer and the manufacturer’s SDS to ensure proper
precautionary steps are taken.
5. Place the system components and the vacuum pump in protective packaging.
„ A desiccant should be placed in the packaging to minimize moisture exposure.
6. Store components in a room with a humidity level of less than 80 percent.
?
NOTE During the time the pump is stored, also run it for five minutes every three months to
keep the seals lubricated.
FlexTRAK Series 2MB Material Handler Addendum Installation
© 2023 Nordson Corporation 3-5
3.5 Placing the System
Once the FlexTRAK-2MB has been unpacked, it must be moved to its location at the facility.
WARNING! Hazardous voltages are found within the lower enclosure of the
FlexTRAK-2MB System. Use extreme caution to prevent injury to personnel
or damage to equipment. Only qualified technicians should install this
equipment.
WARNING! Only qualified technicians should perform system installation. It
is recommended that at least two persons guide the system while it is being
positioned on the factory floor.
WARNING! When a chiller is hooked up to the FlexTRAK, a secondary
water containment system, such as a drip pan, should be installed underneath
the FlexTRAK in order to comply with SEMI-S2 safety guidelines. This
system should include leak detection and, if possible, should have a large
enough capacity to hold all of the water used in the cooling system.
To place the system in its factory location:
1. Carefully transport the system to the installation site using a forklift or floor jack.
?
NOTE To move the system short distances, you can use the wheels attached to the bottom of the
plasma system. Then raise or lower the levelers to the desired height using a wrench.
2. Once the system has been positioned in the desired location, slowly lower the forklift until
the chamber rails are approximately at the desired height.
3. Unscrew each leveler (footpad) until it touches the floor.
4. Lower and remove the forklift (Figure 3-2).
5. Place a level across the top of the system to make sure that it is level front-to-back and side-
to-side.
6. Use an open-end wrench to turn the height adjustment nut in the desired direction to raise or
lower the system to the correct position (Figure 3-2).
