FlexTRAK Series 2MB Material Handler Addendum Safety
© 2023 Nordson Corporation 2-5
2.7.2 Precautions
When lifting, transporting, and lowering heavy or large loads, personnel should observe the following
precautions:
• Stand close to the load to be lifted and place your feet at shoulder width.
• Firmly grip the load and bring the load close to your body.
• Lift your head and shoulders first and with your back straight, use the strength of your legs
to slowly and smoothly raise yourself up.
• DO NOT twist your body. Change direction by first moving your feet.
• When transporting the load on a cart or a lifting device, reduce back strain by pushing rather
than pulling the load.
• When lowering the load, bend your knees, lower it slowly and smoothly, and keep your
fingers out from under the load.
2.8 Safety Warning Labels
Safety warning labels on the material handler point out areas where personnel must use extreme caution
to prevent serious injury and property damage. Table 2-2 shows the warning labels that may be found on
your material handler or optional equipment. The locations of warning labels on a typical material
handler are shown in Figure 2-1 through Figure 2-4.
Table 2-2 Safety Hazard Labels
Label Part Number Description
7219555
Read Manual - Warns personnel that the manual
must be read and understood before proceeding
in this area.
7219554
Pinch Point - Cautions personnel of potential
pinch point hazards.
7242012
Moving Parts Warning - Warns personnel to
keep hands and fingers away from mechanisms
that could cause injury.
7218729
Hot Surface Warning - Warns personnel of hot
surfaces that may cause burns if touched.
7218727
Gloves - Cautions personnel to use gloves
around Hot Surfaces Warnings.
7219553
Forklift Point - Points to an acceptable entry
point for a forklift to lift the machine.
FlexTRAK Series 2MB Material Handler Addendum Safety
2-6 © 2023 Nordson Corporation
Label Part Number Description
7219556
Seismic Tie Down - Indicates where seismic tie
downs are to be attached.
7243245
Hazardous Voltage Warning - Warns personnel
of areas where high voltage is present which
may cause severe injury or death.
199097
Radiation Warning - Warns personnel of a non-
ionizing radiation hazard. The plasma system
uses an RF generator, which produces RF
energy at levels that may cause burns. Improper
connections or operations without protective
covering may result in RF radiation exceeding
safety standards.
7218728
Arc Flash Potential - Warns personnel that
while the machine is energized that an arc can
occur between this device and a tool in hand.
FlexTRAK Series 2MB Material Handler Addendum Safety
© 2023 Nordson Corporation 2-7
Item Description
1 Read Manual
2 Pinch Point Hazard
3 Radiation Hazard
4 Moving Parts Warning
5 Hot Surface Warning
6 Gloves
7 Seismic Tie Down
8 Hazardous Voltage
Figure 2-1 Safety Hazard Labels - Front Right View
2
3
4
5
6
1
2
2
3
7
8
