FlexTRAK Series 2MB Mater ial Handler Adden dum Safety © 2023 Nordson Corporation 2-7 Item Description 1 Read Manual 2 Pinch Point Hazard 3 Radiation Hazard 4 Moving Parts Warning 5 Hot Surface Warning 6 Gloves 7 Seismic…
FlexTRAK Series 2MB Material Handler Addendum Safety
2-6 © 2023 Nordson Corporation
Label Part Number Description
7219556
Seismic Tie Down - Indicates where seismic tie
downs are to be attached.
7243245
Hazardous Voltage Warning - Warns personnel
of areas where high voltage is present which
may cause severe injury or death.
199097
Radiation Warning - Warns personnel of a non-
ionizing radiation hazard. The plasma system
uses an RF generator, which produces RF
energy at levels that may cause burns. Improper
connections or operations without protective
covering may result in RF radiation exceeding
safety standards.
7218728
Arc Flash Potential - Warns personnel that
while the machine is energized that an arc can
occur between this device and a tool in hand.
FlexTRAK Series 2MB Material Handler Addendum Safety
© 2023 Nordson Corporation 2-7
Item Description
1 Read Manual
2 Pinch Point Hazard
3 Radiation Hazard
4 Moving Parts Warning
5 Hot Surface Warning
6 Gloves
7 Seismic Tie Down
8 Hazardous Voltage
Figure 2-1 Safety Hazard Labels - Front Right View
2
3
4
5
6
1
2
2
3
7
8
FlexTRAK Series 2MB Material Handler Addendum Safety
2-8 © 2023 Nordson Corporation
Item Description
1 Read Manual
2 Moving Parts Warning
Figure 2-2 Safety Hazard Labels (Front Upper Right)
2
1
