FlexTRAK Series 2MB Mater ial Handler Adden dum Tour of HMI Softw are for the Material Handler © 2023 Nordson Corporation 5-23 Control Description Y TOP ALARM Indicates the status of the Y-axi s Top Alarm sensor. A red l…

FlexTRAK Series 2MB Material Handler Addendum Tour of HMI Software for the Material Handler

Control Description

SLOT 1 C0-C7

Y BOT POS BIT 1

Indicates the status of the Y-axis Bottom Position Bit 1 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT POS BIT 2

Indicates the status of the Y-axis Bottom Position Bit 2 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT POS BIT 4

Indicates the status of the Y-axis Bottom Position Bit 4 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT PZONE

Indicates the status of the Y-axis Bottom PZone sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT MANUAL

Indicates the status of the Y-axis Bottom Manual sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT HOME COMP

Indicates the status of the Y-axis Bottom Home Comp sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT PC/WC

Indicates the status of the Y-axis Bottom PC/WC sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT ALARM

Indicates the status of the Y-axis Bottom Alarm sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

SLOT 1 D0-D7

Y TOP POS BIT 1

Indicates the status of the Y-axis Top Position Bit 1 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP POS BIT 2

Indicates the status of the Y-axis Top Position Bit 2 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP POS BIT 4

Indicates the status of the Y-axis Top Position Bit 4 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP PZONE

Indicates the status of the Y-axis Top PZone sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP MANUAL

Indicates the status of the Y-axis Top Manual sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP HOME COMP

Indicates the status of the Y-axis Top Home Comp sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP PC/WC

Indicates the status of the Y-axis Top PC/WC sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

FlexTRAK Series 2MB Material Handler Addendum Tour of HMI Software for the Material Handler

Control Description

Y TOP ALARM

Indicates the status of the Y-axis Top Alarm sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

SLOT 2 A0-A7

CONVEY TOP POS BIT 1

Indicates the status of the Conveyor Top Position Bit 1 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP POS BIT 2

Indicates the status of the Conveyor Top Position Bit 2 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP POS BIT 4

Indicates the status of the Conveyor Top Position Bit 4 sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP PZONE

Indicates the status of the Conveyor Top PZone sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP MANUAL

Indicates the status of the Conveyor Top Manual sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP HOME COMP

Indicates the status of the Conveyor Top Home Comp sensor. A red

light means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP PC/WC

Indicates the status of the Conveyor Top PC/WC sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

CONVEY TOP ALARM

Indicates the status of the Conveyor Top Alarm sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

SLOT 2 B0-B7

CONVEY HOMESENS

Indicates the status of the Conveyor Home sensor. A red light means

the I/O point is off (open/disconnected), and a green light means that

it is on (closed/connected).

Z TOP HOMESENS

Indicates the status of the Z-axis Top Home sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Z BOT HOMESENS

Indicates the status of the Z-axis Bottom Home sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y TOP HOMESENS

Indicates the status of the Y-axis Top Home sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

Y BOT HOMESENS

Indicates the status of the Y-axis Bottom Home sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

LANE 1 SENSOR 1

Indicates the status of the Lane 1 Sensor 1. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

FlexTRAK Series 2MB Material Handler Addendum Tour of HMI Software for the Material Handler

Control Description

LANE 1 SENSOR 2

Indicates the status of the Lane 1 Sensor 2. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 1 SENSOR 3

Indicates the status of the Lane 1 Sensor 3. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

SLOT 2 C0-C7

LANE 1 SENSOR 4

Indicates the status of the Lane 1 Sensor 4. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 1 SENSOR 5

Indicates the status of the Lane 1 Sensor 5. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 1 STOPPER UP

Indicates the status of the Lane 1 Stopper Up sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

LANE 1 STOPPER DN

Indicates the status of the Lane 1 Stopper Down sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

LANE 2 SENSOR 1

Indicates the status of the Lane 2 Sensor 1. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 2 SENSOR 2

Indicates the status of the Lane 2 Sensor 2. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 2 SENSOR 3

Indicates the status of the Lane 2 Sensor 3. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 2 SENSOR 4

Indicates the status of the Lane 2 Sensor 4. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

SLOT 2 D0-D7

LANE 2 SENSOR 5

Indicates the status of the Lane 2 Sensor 5. A red light means the I/O

point is off (open/disconnected), and a green light means that it is on

(closed/connected).

LANE 2 STOPPER UP

Indicates the status of the Lane 2 Stopper Up sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

LANE 2 STOPPER DN

Indicates the status of the Lane 2 Stopper Down sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

GRIP DETECT T1 LFT

Indicates the status of the Grip Detection T1 Left sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).

GRIP DETECT T1 RIT

Indicates the status of the Grip Detection T1 Right sensor. A red light

means the I/O point is off (open/disconnected), and a green light

means that it is on (closed/connected).
