FlexTRAK Series 2MB Material Handler Addendum Tour of HMI Software for the Material Handler
© 2023 Nordson Corporation 5-23
Control Description
Y TOP ALARM
Indicates the status of the Y-axis Top Alarm sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
SLOT 2 A0-A7
CONVEY TOP POS BIT 1
Indicates the status of the Conveyor Top Position Bit 1 sensor. A red
light means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP POS BIT 2
Indicates the status of the Conveyor Top Position Bit 2 sensor. A red
light means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP POS BIT 4
Indicates the status of the Conveyor Top Position Bit 4 sensor. A red
light means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP PZONE
Indicates the status of the Conveyor Top PZone sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP MANUAL
Indicates the status of the Conveyor Top Manual sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP HOME COMP
Indicates the status of the Conveyor Top Home Comp sensor. A red
light means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP PC/WC
Indicates the status of the Conveyor Top PC/WC sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
CONVEY TOP ALARM
Indicates the status of the Conveyor Top Alarm sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
SLOT 2 B0-B7
CONVEY HOMESENS
Indicates the status of the Conveyor Home sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
Z TOP HOMESENS
Indicates the status of the Z-axis Top Home sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
Z BOT HOMESENS
Indicates the status of the Z-axis Bottom Home sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
Y TOP HOMESENS
Indicates the status of the Y-axis Top Home sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
Y BOT HOMESENS
Indicates the status of the Y-axis Bottom Home sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
LANE 1 SENSOR 1
Indicates the status of the Lane 1 Sensor 1. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
FlexTRAK Series 2MB Material Handler Addendum Tour of HMI Software for the Material Handler
5-24 © 2023 Nordson Corporation
Control Description
LANE 1 SENSOR 2
Indicates the status of the Lane 1 Sensor 2. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 1 SENSOR 3
Indicates the status of the Lane 1 Sensor 3. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
SLOT 2 C0-C7
LANE 1 SENSOR 4
Indicates the status of the Lane 1 Sensor 4. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 1 SENSOR 5
Indicates the status of the Lane 1 Sensor 5. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 1 STOPPER UP
Indicates the status of the Lane 1 Stopper Up sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
LANE 1 STOPPER DN
Indicates the status of the Lane 1 Stopper Down sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
LANE 2 SENSOR 1
Indicates the status of the Lane 2 Sensor 1. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 2 SENSOR 2
Indicates the status of the Lane 2 Sensor 2. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 2 SENSOR 3
Indicates the status of the Lane 2 Sensor 3. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 2 SENSOR 4
Indicates the status of the Lane 2 Sensor 4. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
SLOT 2 D0-D7
LANE 2 SENSOR 5
Indicates the status of the Lane 2 Sensor 5. A red light means the I/O
point is off (open/disconnected), and a green light means that it is on
(closed/connected).
LANE 2 STOPPER UP
Indicates the status of the Lane 2 Stopper Up sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
LANE 2 STOPPER DN
Indicates the status of the Lane 2 Stopper Down sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
GRIP DETECT T1 LFT
Indicates the status of the Grip Detection T1 Left sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
GRIP DETECT T1 RIT
Indicates the status of the Grip Detection T1 Right sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
FlexTRAK Series 2MB Material Handler Addendum Tour of HMI Software for the Material Handler
© 2023 Nordson Corporation 5-25
Control Description
GRIP CLOSED TOP
Indicates the status of the Grip Closed Top sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
GRIP OPEN TOP
Indicates the status of the Grip Open Top sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
NOT USED This signal is unused.
SLOT 3 A0-A7
GRIP DETECT B1 LFT
Indicates the status of the Grip Detection B1 Left sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
GRIP DETECT B1 RIT
Indicates the status of the Grip Detection B1 Right sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
GRIP CLOSED BOT
Indicates the status of the Grip Closed Bottom sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
GRIP OPEN BOT
Indicates the status of the Grip Open Bottom sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
INTERLOCK BYPASS
Indicates the status of the Interlock Bypass sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
E-STOP INTERLOCK
Indicates the status of the E-Stop Interlock Bypass sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
COUNTERBAL HI PR
Indicates the status of the Counterbalance High PR sensor. A red
light means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
COUNTERBAL LO PR
Indicates the status of the Counterbalance Low PR sensor. A red light
means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
SLOT 3 B0-B7
FLEXTRAK MR
Indicates the status of the FlexTRAK MR sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
FLEXTRAK BA
Indicates the status of the FlexTRAK BA sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
FLEXTRAK CHAM CLR
Indicates the status of the FlexTRAK Chamber Clear sensor. A red
light means the I/O point is off (open/disconnected), and a green light
means that it is on (closed/connected).
LANE 1 DS MR
Indicates the status of the Lane 1 DS MR sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
LANE 1 US BA
Indicates the status of the Lane 1 US BA sensor. A red light means
the I/O point is off (open/disconnected), and a green light means that
it is on (closed/connected).
