2.1.3 "MACH SETUP" Window The following describes how to open the "MACH SETUP" window . • Window Layout (1) Press the [SYSTEM] button on the main menu bar . The "SYS SEL" menu opens. Fig. 3E…

: When pressed, the "Nozzle Type Property" window opens,

enabling the operator to add a new nozzle type.

This function is available only in the "Nozzle Data" tab sheet.

: When pressed, this deletes the selected nozzle type.

This function is available only in the "Nozzle Data" tab sheet.

: When pressed, this opens the "Nozzle Type Property" win-

dow for the selected nozzle type, enabling the operator to

change the nozzle type.

This function is available only in the "Nozzle Data" tab sheet.

: When pressed, this fills all the selected text boxes with the

parameter in the first text box.

: When pressed, this fills all the selected text boxes with

the parameter in the last text box.

: When pressed, this initializes the selection (sets the de-

faults).

01 10-003 5 - 8

AFO01EDTP

2.1 Display of Each Window

2.1.3 "MACH SETUP" Window

The following describes how to open the "MACH SETUP" window.

• Window Layout

(1) Press the [SYSTEM] button on the main menu bar. The "SYS SEL"

menu opens.

Fig. 3E8

(2) Press the [MACH SETUP] button. The "MACH SETUP" window

opens.

Fig. 3E9 "MACH SETUP" Window

0307-005 5-9

AFO01EDTP

2.1 Display of Each Window

3. "System" Window

3.1 Outline of "System" Window

The "System" window is composed of the following items.

"System" Window

Tab Tabs (Tab Sheets) Reference Item Nos.

Device Offset (3.2) Device Offset (3.2.1)

Head (3.2.2)

CPK Offset (3.2.3)

Feeder-A (3.2.4)

Feeder-B (3.2.4)

Nozzle (3.2.5)

Camera Offset (3.2.6)

Lighting (3.2.7)

Auto Operation (3.3) Auto Operation Setup (3.3.1)

P.C.B. Transfer Mode Setup (3.3.2)

Configuration Setup (3.4) Light Tower Setup (3.4.1)

Alarm Setup (3.4.2)

Fig. 3E10

(3.2) through (3.4.2) show the item Nos. to be referred to.

01 10-003 5-10

AFO01EDTP

3.1 Outline of "System" Window
