1.116 User Manual Software Version 6 MACHINE PROGRAMMING STATUS PAGE
Process - Parameters The following table lists all the items that can be displayed in the Process -
Parameters information panel:
Print Mode Front Print Speed Rear Print Speed Front Pressure
Rear Pressure ProFlow System Pressure Print Gap Separation Speed
Paste Dispense Rate Clean Screen Rate 1.2 Forward X Offset Forward Y Offset
Forward Theta Offset Reverse X Offset Reverse Y Offset Reverse Theta Offset
The values of the Process - Parameters are set in the product file of the loaded
product.
The panel can display up to a maximum of 14 items on Display Type 1 and 6
items on Display Type 2.
Rates The following table lists all the items that can be displayed in the Rates
information panel:
Items Description
Batch Count/Limit The first figure displays the amount of boards printed in the current batch. The
second figure displays the total amount of boards to be printed in the current batch.
The batch count limit is set in Batch Limit in the Monitor menu.
Board Count/Limit The first figure displays the amount of boards printed in the current board count.
The second figure displays the total amount of boards to be printed in the current
board count. The board count limit is set in Board Count in the Edit Data menu.
The board count limit allows a separate board count to be set within the total batch
count.
Paste Disp. Cnt/Rate The first figure displays the amount of boards printed since the last paste dispense.
The second figure displays the amount of boards to be printed between each paste
dispense. The paste dispense count/rate is set in Paste Dispense Rate in the Edit
Data menu.
Clean 1 Count/Rate The first figure displays the amount of boards printed since the last screen clean
mode 1 was carried out. The second figure displays the amount of boards to be
printed between each screen clean mode 1. The clean 1 count/rate is set in Screen
Clean Rate 1 in the Edit Data menu. This parameter is only displayed while a
blue or silver under screen cleaner is fitted.
Clean 2 Count/Rate The first figure displays the amount of boards printed since the last screen clean
mode 2 was carried out. The second figure displays the amount of boards to be
printed between each screen clean mode 2. The clean 2 count/rate is set in Screen
Clean Rate 2 in the Edit Data menu. This parameter is only displayed while a
blue or silver under screen cleaner is fitted.
Vortex Stroke/Limit The first figure displays the amount of cleaning strokes carried out since the
Vortex cleaning cassette was replaced. The second figure displays the total
amount of cleaning strokes to be carried out before the cleaning cassette needs
replacing. The Vortex stroke/limit is set in Vortex Cassette Life in the Edit Data
menu. This parameter is only displayed while a Vortex under screen cleaner is
fitted.
Clean Count/Rate The first figure displays the amount of boards printed since the last Vortex screen
clean was carried out. The second figure displays the amount of boards to be
printed between each Vortex screen clean. The clean count/rate is set in Vortex
Clean Rate in the Edit Data menu. This parameter is only displayed while a
Vortex under screen cleaner is fitted.
Print Direction Displays the print direction for the next board to be printed.
The Rates panel can display up to a maximum of 6 items and is only shown on
Display Type 2.
