IMAGE RECORDING
Selecting Save Image saves the inspection object data using the save object
command. This option is only available if image recording in set preferences is
set to VP or PC disk. If the image recording is set to VP disk, the file name is
inspnnn.img, where nnn is the next sequence number to save. If the image
recording is set to PC disk, the file name is inspn.img, where n is a number
cyclingfrom 1 to 5. The first imagesaved afterinitialization isinsp1.img. Files
are overwritten without warning.
NOTE
VP disk saves to the Cognex HD if fitted. It is recommended to use PC disk only
for image recording.
8.40 User Manual Software Version 6
2Di INSPECTION
IMAGE RECORDING
MENU PARAMETERS
Parameter Definition
2D Inspect Rate This parameter sets the number of print cycles between inspection cycles,
with zero indicating no inspection.
Minimum - 0
Maximum - 100
Increments - 1
Default - 0
Stencil Inspect Type This parameter sets the extent of the screen inspection. The options are:
None
Basic
Advanced
Default - Basic
Board Inspect Type This parameter sets the extent of the board inspection. The options are:
None
Basic
Advanced
Default - Basic
Pre-image This parameter sets when a pre-image is taken. The options are:
One - The first board only
Every - Every board
Default - One
Min Sites/Cycle This parameter sets the number of sites to inspect every cycle.
Minimum - Number of Every Cycle sites
Maximum - Total number of sites
Increments - 1
Default - Number of every cycle sites
Warning Limit This parameter determines how many consecutive warnings on the same
site constitute an alarm.
Minimum - 1
Maximum - 20
Increments - 1
Default - 3
Blockage Action This parameter sets the action performed on a blockage alarm. The options
are:
Manual
Automatic
Default - Manual
Blockage Clean This parameter sets the type of screen clean performed on blockage alarm.
The options are:
Mode 1
Mode 2
Default - Mode 1
Smear Action This parameter sets the action performed on a smear alarm. The options
are:
Manual Action
Automatic
Default - Manual
Smear Clean This parameter sets the type of screen clean performed on a smear alarm.
The options are:
Mode 1
Mode 2
Default - Mode 2
Software Version 6 User Manual 8.41
2Di INSPECTION
MENU PARAMETERS
Parameter Definition
Low Paste Action This parameter sets the action performed on a low paste alarm. The
options are:
Manual
Re-print
Default - Manual
Inspect After Clean This parameter sets whether a screen is inspected before the next board is
printed following a screen clean. The options are:
Disabled
Enabled
Default - Disabled
Post Print Alignment This parameter sets whether post print alignment is carried out. The
options are:
Not Performed
Performed
Default - Not Performed
No. Sites This parameter displays the total number of sites.
Minimum - 0
Maximum - 500
Increments - 1
Default - 0
Site Name The unique uppercase name given to a site for identification and which
cannot be mistaken for the name of a created site. The name can have a
maximum of 20 characters.
Site Priority This parameter determines the priority of a site. Where the site is part of a
device, the value applies to the whole device. The options are:
Not Inspected
General
Every Cycle
Default - Every Cycle
Site Alignment This parameter sets what alignment data is reported for each site. The
options are:
X & Y
X Only
Y Only
None
Default - None
Limit Set ID The unique uppercase name given to a set of limits which can be applied to
any site. This enables different sites to be inspected according to different
limits. The name can have a maximum of 20 characters. A maximum of
14 limit sets can be created.
Paste Scaling This parameter enables adjustment of the paste scaling value for the
current site, to cause the value of paste present on the pad, currently
selected in the inspection list, to be reported as 100%. This parameter is
used in conjunction with the Auto Scale function.
Minimum - 0.01
Maximum - 2.00
Increments - 0.01
Default - 1
Site X Coord The coordinate of a site taken from the front left corner of the board, in the
X direction.
Minimum - 0.0mm
Maximum - Board Length
Increments - 0.1mm
Default - 164.1mm
8.42 User Manual Software Version 6
