Stationary Camera Type 33/36 Stationäre Kamera Typ 33/36 101
2.2 Prerequisites and Restrictions
▪ Type 33 stationary cameras can be used in the SX series, X series, D3 and D1 machines.
▪ Type 36 stationary cameras can only be used in D1 machines.
▪ The camera design and the assembly procedure for each camera is generally the same for the indi-
vidual machines. Any differences will be explicitly indicated in this guide.
▪ When using a C&P20 head, make sure that there are no stationary cameras fitted in the same place-
ment area.
▪ When using X series or SX series machines, you may need to move the COT insert, depending on
your machine configuration.
▪ A type 33 stationary camera of version 1 or 2 can only be used in X series machines up to number
326.
From version 3, it can also be used with SIPLACE D series, SX and X series machines of number
326 or higher.
▪ When fitting the camera in an X series or SX4 machine, you will need to have two hotlink cards in
the box PC.
WARNING
Head crash risk by changeover to C&P20 head
When changing the placement head from a TwinHead or CPP to a C&P20, you will need to dis-
mantle all stationary component cameras (stationary P&P, type 33, 55x45, and type 25, 16x16)
from the TwinHead.
If this is not done, there is a risk that the C&P20 head could crash with the camera housing.
WARNING
Head crash by changeover to CPP head
When changing the placement head from a TwinHead to a CPP, you will need to install the sta-
tionary component camera (type 33, 55x45, digital) in the lower position.
Brief Description
Scope of Delivery SIPLACE X Series, D3
102 Stationary Camera Type 33/36 Stationäre Kamera Typ 33/36
2.3 Scope of Delivery
Depending on your machine, you may need one of the following installation kits:
2.3.1 SIPLACE X Series, D3
Installation kit: stationary camera type 33 for CPP head fitted in X series [00119782-xx]
2.3.2 SIPLACE D1
The P&P module in the SIPLACE D1 is supplied in its default configuration with a component camera
stationary P&P (type 36) 32x32 digital [03042491-xx]. This is also included in the delivery package for
the HRK P&P module for SIPLACE D1 machines.
Installation of the camera is the same as that for the stationary camera described here (type 33) 55x45
digital.
Installation kit: stationary camera (type 33) 55x45 digital in the D1
To convert a D1 for the "component camera stationary P&P (type 33) 55x45", you only need the camera
itself as all attached parts of the "component camera stationary P&P (type 36) 32x32 digital" can still be
used.
Quantity Designation Item No.
1 Component camera, stationary, P&P (type 33) 55 x 45, digital 03016339- xx
1 Sandwich plate for fiducial complete – L600 03022077- xx
4 ISO4762 - M6x35-8.8, galvanized, DSP8 03069136- xx
2 DIN913-M6x50-ST 03005958- xx
1 CAN bus: IC camera 03050239- xx
1 Waste box for TwinHead 03003047- xx
1 Fixture plate for waste box 03003048- xx
2 ISO4762 - M6 x 12-A2-70 03042572- xx
1 Assembly instructions "stationary camera type 33/36" DE+EN 00196608- xx
1 Reject bin sensors for upgrade 03079029- xx
Quantity Designation Item No.
1 Component camera, stationary, P&P (type 33) 55x45, digital 03016339- xx
2 DIN913-M6x50 (set screws) 03005958- xx
NOTICE
Same parts for camera type 33 in D1 as required for camera type 36
For the D1 you can use the same screws and "sandwich plate for fiducial IC camera"
[03039370-xx] as were used for the type 36 stationary camera.
The "component reject assembly for P&P head" [03047406-xx] remains in the machine.
Brief Description
SIPLACE SX1/SX2 Scope of Delivery
Stationary Camera Type 33/36 Stationäre Kamera Typ 33/36 103
2.3.3 SIPLACE SX1/SX2
Installation kit: stationary camera type 33 for CPP head fitted in SX1/SX2 machines
[00519902-xx]
2.3.4 SIPLACE DX1/DX2
The TwinHead in the SIPLACE DX1/DX2 is supplied in its default configuration with a "component cam-
era stationary (type 36) 32x32 digital" [03042491-xx].
Installation of the camera is the same as that for the stationary camera described here (type 33, 55x45
digital) for SIPLACE SX1/SX2.
Optional installation "stationary camera (type 33) 55x45 digital in the DX1/DX2"
The standard stationary camera for the DX1/DX2 with a TwinHead is the "component camera stationary
(type 36) 32x32 digital" [03042491-xx].
To convert a DX1/DX2 for the "component camera stationary P&P (type 33) 55x45", you only need the
camera itself as all attached parts of the "component camera stationary P&P (type 36) 32x32 digital" can
still be used.
Quantity Designation Item No.
1 Component camera, stationary, P&P (type 33) 55 x 45, digital 03016339- xx
4 DIN912-M6x22-A2-70 (for support plate) 03045092- xx
1 Support plate assembly SP1 03070836- xx
1 Support plate assembly SP2 03070862- xx
4 DIN912-M6x12-A2-70 03045087- xx
4 DIN6325–5m6x18-St (parallel pins) 00311385- xx
1 Holder for reject bins P001 03063283- xx
2 DIN912-M6x10-A2-70 00201106- xx
1 Reject bin assembly 03072806- xx
1 Assembly instructions "stationary camera type 33/36" DE+EN 00196608- xx
NOTICE
SIPLACE SX1/SX2 – support plate
If there is no stationary camera installed at location 1, you will need a "support plate assembly
SP1" [03070836-xx].
For location 2 you need the "support plate assembly SP2" [03070862-xx].
The camera and reject bin are fitted onto the support plate.
The support plate which is not needed in each case can be disposed of.
Quantity Designation Item No.
1 Component camera, stationary, P&P (type 33) 55x45, digital 03016339- xx
2 DIN913-M6x50 (set screws) 03005958- xx
NOTICE
Same parts for cameras of type 33 and 36
In the DX1/DX2 you can use the same screws and support plates for the type 33 stationary
cameras as were used for the type 36 stationary camera.
The component reject unit and holder remain in the machine.
