Brief Description
SIPLACE SX1/SX2 Scope of Delivery
Stationary Camera Type 33/36 Stationäre Kamera Typ 33/36 103
2.3.3 SIPLACE SX1/SX2
Installation kit: stationary camera type 33 for CPP head fitted in SX1/SX2 machines
[00519902-xx]
2.3.4 SIPLACE DX1/DX2
The TwinHead in the SIPLACE DX1/DX2 is supplied in its default configuration with a "component cam-
era stationary (type 36) 32x32 digital" [03042491-xx].
Installation of the camera is the same as that for the stationary camera described here (type 33, 55x45
digital) for SIPLACE SX1/SX2.
Optional installation "stationary camera (type 33) 55x45 digital in the DX1/DX2"
The standard stationary camera for the DX1/DX2 with a TwinHead is the "component camera stationary
(type 36) 32x32 digital" [03042491-xx].
To convert a DX1/DX2 for the "component camera stationary P&P (type 33) 55x45", you only need the
camera itself as all attached parts of the "component camera stationary P&P (type 36) 32x32 digital" can
still be used.
Quantity Designation Item No.
1 Component camera, stationary, P&P (type 33) 55 x 45, digital 03016339- xx
4 DIN912-M6x22-A2-70 (for support plate) 03045092- xx
1 Support plate assembly SP1 03070836- xx
1 Support plate assembly SP2 03070862- xx
4 DIN912-M6x12-A2-70 03045087- xx
4 DIN6325–5m6x18-St (parallel pins) 00311385- xx
1 Holder for reject bins P001 03063283- xx
2 DIN912-M6x10-A2-70 00201106- xx
1 Reject bin assembly 03072806- xx
1 Assembly instructions "stationary camera type 33/36" DE+EN 00196608- xx
NOTICE
SIPLACE SX1/SX2 – support plate
If there is no stationary camera installed at location 1, you will need a "support plate assembly
SP1" [03070836-xx].
For location 2 you need the "support plate assembly SP2" [03070862-xx].
The camera and reject bin are fitted onto the support plate.
The support plate which is not needed in each case can be disposed of.
Quantity Designation Item No.
1 Component camera, stationary, P&P (type 33) 55x45, digital 03016339- xx
2 DIN913-M6x50 (set screws) 03005958- xx
NOTICE
Same parts for cameras of type 33 and 36
In the DX1/DX2 you can use the same screws and support plates for the type 33 stationary
cameras as were used for the type 36 stationary camera.
The component reject unit and holder remain in the machine.
Brief Description
Tools and Equipment Required SIPLACE SX 4
104 Stationary Camera Type 33/36 Stationäre Kamera Typ 33/36
2.3.5 SIPLACE SX 4
Installation kit: stationary camera type 33 an SX4 [00519828-xx]
2.4 Tools and Equipment Required
▪ Set of Allen keys
▪ Allen key with T-handle size 5 and 6
▪ Set of screwdrivers
▪ Universal pliers
▪ Microfiber cloth for cleaning optical assemblies
▪ For cameras up to and including FS04: 2x DIN913-M6x50 (set screws) [03005958-xx]
▪ Calibration tool version 3 [03010565-xx]
▪ Nozzle/ZP correction P&P [03008862-xx] (for calibration up to SW705.02)
▪ 10x self-adhesive base for cable ties [03064015-xx]
▪ 10x cable ties, B=2.5 mm, L=102 mm, Panduit [00308458-xx]
▪ Service manual for your machine
▪ Circuit diagrams for your machine where necessary
▪ Assembly instructions "reject bin query X series/D3/SX4, DE+EN" [00194716-xx] or
Assembly instructions "reject bin query SX1/SX2, DE+EN" [00196615-xx]
2.5 Required Working Time
The complete installation procedure takes between 40 and 80 minutes, depending on the machine type,
installation location and whether the COT insert needs to be moved or not.
Quantity Designation Item No.
2 Distance plate for IC camera SX4 03080912- xx
2 ISO7379-8x40-12.9 03005648- xx
2 ISO 4762 - M 6 x 50-A2-70 03042580- xx
4 ISO 4762 - M 6 x 25-A2-70 03042575- xx
1 Component camera, stationary, P&P (type 33) 55 x 45, digital 03016339- xx
1 Waste box TwinHead SX4 assembly
This contains:
03082159- xx
1 Fixture bracket module assembly 03081981- xx
1 Reject bin assembly 03072806- xx
4 DIN7984-M6x12-A2-70 03081847- xx
1 Holder for reject bins P001 03063283- xx
1 Assembly instructions "stationary camera type 33/36" DE+EN 00196608- xx
2 DIN913-M6x50 (set screws) 03005958- xx
NOTICE
Second person
You might find it advisable to enlist the help of a second person for certain tasks.
Installation
Stationary Camera Type 33/36 Stationäre Kamera Typ 33/36 105
3 Installation
NOTICE
Usage, differences between the cameras
The type 33 stationary cameras can be installed in SX and X series, D3 and D1 SIPLACE ma-
chines; type 36 cameras can be installed in D1 machines. The camera design and the assem-
bly procedure for each camera is generally the same for the individual machines. Any
differences will be explicitly indicated in this guide.
CAUTION
Do not hold or carry the camera by its electronics unit.
The camera electronics assembly is a sensitive unit and can be easily damaged.
► Only hold or carry the camera by its metal frame.
► Always pull the illumination unit carefully up and off.
► The metal housing must always be hooked out of the lower section of the camera.
NOTICE
The upper section of the camera has a fixed assignment to the bottom section of the camera!
The upper section of the camera may not be used with a different bottom section. Both the up-
per and lower sections are mechanically and electrically coordinated and may not be ex-
changed for use with other cameras.
► The serial and version numbers of the top and bottom sections of the camera must be iden-
tical.
