2 Brief description
2.1 Scope of delivery
Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021 123
2.1.2 Package for vacuum pump at PA2 (old vacuum pump)
This package is required if a SIPLACE C&P20x is installed in placement area 2.
Vacuum pump 2 for SIPLACE X-Series S V2 [03148966‑xx]
Quantity Designation Item no.
1 Cover fan, one part 03052317-xx
1 Flange sheet complete 03084232-xx
1 Exhaust duct vacuum pump SX4 03084244-xx
1 Safety guard for fan 03064989-xx
1 Installation kit for vacuum pump
Consisting of:
03086345-xx
3 Push-in L-fitting QS-1/2-10 03038816-xx
1 Distributor block 03086336-xx
1 Vacuum filter F10 03070370-xx
1 Sealing screw R3/4 St+NBR 03004775-xx
2 Push-in L-fitting QSL-1/2-12 03080578-xx
3 Push-in L-fitting QSL-1/2-10 03081051-xx
1 Reducing nipple G1 - G3/4 03088251-xx
2 Double nipple, detachable G3/4 Ms 03038435-xx
1 Double nipple G3/4 brass 03093668-xx
1 Air box right with felt 03119452-xx
1 Exhaust air duct vacuum pump XS SP1 03115589-xx
1 Support plate for vacuum pump 03079501-xx
1 Becker VX 4.25 vacuum pump with cable 03128463-xx
2 Sliding foil 03087279-xx
2 Brief description
2.1 Scope of delivery
124 Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021
2.1.3 Package for vacuum pump IE3 at PA1 (new vacuum pump)
This package is required if a SIPLACE C&P20x is installed in placement area 1.
Vacuum pump IE3 1 SIPLACE X-Series S V2 [03224400‑xx]
Quantity Designation Item no.
1 Cover fan, one part 03052317-02
1 Safety guard for fan 03064989-01
1 Installation kit for vacuum pump 03086345-03
3 Push-in L-fitting QS-1/2-10 03038816-01
1 Distributor block 03086336-01
1 Vacuum filter F10 03070370-01
1 Sealing screw R3/4 St+NBR 03004775-01
2 Push-in L-fitting QSL-1/2-12 03080578-01
3 Push-in L-fitting QSL-1/2-10 03081051-01
1 Reducing nipple G1 - G3/4 03088251-01
2 Double nipple, detachable G3/4 Ms 03038435-01
1 Double nipple G3/4 brass 03093668-01
1 Push-in L-fitting QSL-1/2-10 03081051-01
2 Push-in L-fitting QSL-1/2-12 03080578-01
1 Reducing nipple G1 - G3/4 03088251-01
1 Air box left with felt 03119454-01
1 Exhaust air duct vacuum pump XS SP4 03115590-01
1 Set of parts IE3-Vac. pump X-Series S 03216960-01
1 Support sheet 03217598-01
8 ISO 4762 - M 5 x 10-A2-70 03042560-01
4 ISO 7090 - 5 - 200 HV - A2 03064907-01
1 Installation kit for vacuum pump 03086345-03
8 BN 11252-M 4 x 10-10.9 03028924-01
1 Flange sheet assembly 03217701-01
1 Wedge assy. right 03217729-01
1 Vacuum pump support plate assembly 03217727-01
1 Wedge assy. left. 03217730-01
1 Exhaust duct welding assembly 03223353-01
1 Vacuum pump interface plate assembly 03223600-01
2 ISO 4762 - M 5 x 8-A2-70 03042559-01
2 Pump assembly fixture 03224407-01
1 Becker VX 4.25 IE3 vacuum pump with cable 03212135-01
2 Brief description
2.1 Scope of delivery
Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021 125
2.1.4 Package for vacuum pump IE3 at PA2 (new vacuum pump)
This package is required if a SIPLACE C&P20x is installed in placement area 2.
Vacuum pump IE3 2 X-Series S V2 [03224402‑xx]
Quantity Designation Item no.
1 Cover fan, one part 03052317-02
1 Safety guard for fan 03064989-01
1 Installation kit for vacuum pump 03086345-03
3 Push-in L-fitting QS-1/2-10 03038816-01
1 Distributor block 03086336-01
1 Vacuum filter F10 03070370-01
1 Sealing screw R3/4 St+NBR 03004775-01
2 Push-in L-fitting QSL-1/2-12 03080578-01
3 Push-in L-fitting QSL-1/2-10 03081051-01
1 Reducing nipple G1 - G3/4 03088251-01
2 Double nipple, detachable G3/4 Ms 03038435-01
1 Double nipple G3/4 brass 03093668-01
1 Push-in L-fitting QSL-1/2-10 03081051-01
2 Push-in L-fitting QSL-1/2-12 03080578-01
1 Reducing nipple G1 - G3/4 03088251-01
1 Air box right with felt 03119452-01
1 Exhaust air hose vacuum pump XS SP1 03115589-01
1 Set of parts IE3-Vac. pump X-Series S 03216960-01
1 Support sheet 03217598-01
8 ISO 4762 - M 5 x 10-A2-70 03042560-01
4 ISO 7090 - 5 - 200 HV - A2 03064907-01
1 Installation kit for vacuum pump 03086345-03
8 BN 11252-M 4 x 10-10.9 03028924-01
1 Flange sheet assembly 03217701-01
1 Wedge assy. right 03217729-01
1 Vacuum pump support plate assembly 03217727-01
1 Wedge assy. left. 03217730-01
1 Exhaust duct welding assembly 03223353-01
1 Vacuum pump XS interface plate assembly 03223600-01
2 ISO 4762 - M 5 x 8-A2-70 03042559-01
2 Pump assembly fixture 03224407-01
1 Becker VX 4.25 IE3 vacuum pump with cable 03212135-01
2.1.5 Conversion kit 110V for vacuum pump IE3
This conversion kit is required if the machine is operated with 110V.
Conversion kit 110V for vacuum pump IE3 [03224408‑xx]
Quantity Designation Item no.
2 Power circuit breaker 3RV2 3-pin 3.5-5A 03116399-01
