2 Brief description
2.1 Scope of delivery
Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021 127
2.1.9 Vacuum valve/bypass converter
The vacuum valve or bypass converter is required if only one head is supplied by a vacuum pump
(mixed mode).
Quantity Designation Item no.
1 Vacuum valve Becker ST 613-0-2 03109300‑xx
1 Reducing socket, female IG = 1 Rp AG = 1/2 R 03123422‑xx
or
1 Bypass converter 03222472‑xx
1 Push-in L-fitting QS-1/2-10 03038816-xx
2.1.10 Conversion kit for vacuum pump operation in SIPLACE C&P20
This conversion kit is required to convert a SIPLACE C&P20A/M/P from compressed air operation
to vacuum operation.
Conversion kit for vacuum pump operation SIPLACE C&P20 [00119790‑xx]
Quantity Designation Item no.
1 NRS vacuum pump mode C&P20 03049840-01
1 Aperture ring, assy. C+P20 03046348-01
3 ISO 4762 - M 3 x 10-A2-70 03042543-01
3 DIN 125-A 3.2-140HV-A2 00316904-01
2.1.11 Upgrade kit for pressure sensor vacuum in SIPLACE C&P20 P/P2/M2
This upgrade kit is needed for each retrofitted SIPLACE C&P20 P/P2/M2.
Upgrade kit - pressure sensor for vacuum SIPLACE C&P20P [03108457‑xx]
Quantity Designation Item no.
1 Pressure sensor gantry distributor C&P20P assembly 03104322-xx
3 Cable ties, B=2.5mm, L=102mm Panduit 00308458-xx
2.1.12 Bridging plug
A bridging plug is required if only one vacuum pump is connected.
Quantity Designation Item no.
1 Bridging plug vacuum pump connection 03055299‑xx
2.1.13 Support plate
A support plate may be needed for each vacuum pump, depending on the machine number.
Quantity Designation Item no.
1 Support plate 03095110‑xx
2 Brief description
2.2 Preconditions
128 Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021
2.2 Preconditions
Machines with vacuum pump have a higher energy and a lower compressed air consumption than
machines without a vacuum pump. Therefore, adjust the power and compressed air supply to the
relevant specifications.
The SIPLACE C&P20P/M2/P2/M3 is equipped for vacuum operation as a default.
If this has been converted for compressed air mode, it can be converted back again for vacuum
mode, using the "Aperture ring assembly C&P20 P" [03116883Sxx] conversion kit.
See also
2 3.4 "Converting the SIPLACE C&P20x" [}136]
2.3 Restrictions
The SIPLACE Twin and the SIPLACE CPP are not compatible with vacuum pump operation.
The proportional controller (pressure control valve) needs to be operated with compressed air for
all placement heads.
The SIPLACE Twin is supplied by the proportional controller (pressure control valve). Conversion
to vacuum mode is therefore not possible.
The holding circuit of a SIPLACE CPP is not designed for vacuum operation.
NOTICE
Return cylinder unable to move out
Do not convert the pneumatic supply for the gantry affected to vacuum mode. If the com-
pressed air supply for this head is converted to vacuum operation, the return cylinder will be
unable to move out and the Z axis will remain in its top position.
2.4 Tools and equipment required
●
Standard tooling
●
Fork wrench, size 10
●
Fork wrench, size 36
●
Shortened Allen keys
●
Set of Philips screwdrivers
●
Side cutter
●
Snipe nose pliers straight, Festo ZRS 7658 [00381443‑xx]
●
Unlocking tool for Q8 [03047090-xx]
●
Unlocking tool for QSC-10H [03051853-xx]
●
Fork wrench SW36 [03090043-xx]
●
Service manual for your machine
Enlist the help of a second person when installing the vacuum pump.
Have a pallet truck and a suitable pallet ready for use.
2 Brief description
2.5 Vacuum pump - special features
Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021 129
2.5 Vacuum pump - special features
The vacuum pump is switched on and off with the machine. The software automatically takes into
account a stopping time of six minutes on switch-off, to prevent the motor overheating from the in-
rush current peaks.
NOTICE
Maximum of two SIPLACE C&P20x
This vacuum pump can supply a maximum of two SIPLACE C&P20x. If using a placement
machine with four SIPLACE C&P20x, you therefore need two vacuum pumps. These
vacuum pumps are fitted at locations 1 and 4, behind the COT inserts in the machine base.
NOTICE
Retrofit each machine separately
The vacuum pump is connected to the power supply for the placement machine and can
therefore only be operated when the machine is switched on. When a line is converted to
vacuum operation, each machine in the line therefore needs to have its own vacuum
pumps.
