2 Brief description 2.5 Vacuum pump - special features 130 Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021
2 Brief description
2.5 Vacuum pump - special features
Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021 129
2.5 Vacuum pump - special features
The vacuum pump is switched on and off with the machine. The software automatically takes into
account a stopping time of six minutes on switch-off, to prevent the motor overheating from the in-
rush current peaks.
NOTICE
Maximum of two SIPLACE C&P20x
This vacuum pump can supply a maximum of two SIPLACE C&P20x. If using a placement
machine with four SIPLACE C&P20x, you therefore need two vacuum pumps. These
vacuum pumps are fitted at locations 1 and 4, behind the COT inserts in the machine base.
NOTICE
Retrofit each machine separately
The vacuum pump is connected to the power supply for the placement machine and can
therefore only be operated when the machine is switched on. When a line is converted to
vacuum operation, each machine in the line therefore needs to have its own vacuum
pumps.
2 Brief description
2.5 Vacuum pump - special features
130 Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021
3 Installation
3.1 Key information about the pneumatics and vacuum supply
Assembly Instructions / Montageanleitung SIPLACE X-Series S (from/ab Hxxxx) Option Vacuum Pump 02/2021 131
3 Installation
CAUTION
Safety instructions and manufacturer's instructions
In addition to the safety instructions in the introductory chapter, the manufacturer's safety
instructions, installation and setup instructions apply to the vacuum pump and must be ob-
served.
NOTICE
Same procedure
The installation is usually shown using the example of the old vacuum pump version.
Installation of the new version follows the same procedure. Any relevant differences will be
mentioned explicitly.
3.1 Key information about the pneumatics and vacuum
supply
CAUTION
Compressed air
Never turn the compressed air on during the conversion, as this could lead to the place-
ment head being irreparably damaged, depending on the installation status.
The following diagram shows the conversion of a machine with two SIPLACE C&P20A/M/P to
vacuum pump operation.
A maximum of two SIPLACE C&P20A/M/P can be connected to one vacuum pump.
Preconditions (according to machine configuration) see 2.5 "Vacuum pump - special fea-
tures" [}129].
CAUTION
SIPLACE Twin and SIPLACE CPP
When using a SIPLACE Twin or CPP, never convert the pneumatic supply, gantry distrib-
utor or trailing cable! If you do, there is no guarantee that the SIPLACE Twin/CPP will func-
tion properly.
CAUTION
Switching the machine on and off
Avoid switching the machine and vacuum pump on and off multiple times within a short
period. This can have a negative influence on the service life of the pump.
The machine monitors when the vacuum pump is switched on and off (e.g. after longer production
standstill times).
