Driver Unit LAF-10106-01 Driver Unit SHEET 1/1 Driver Unit TB2 TERMINAL BLOCK PS4 DC SUPPL Y 48V PS2 DC SUPPL Y +5V , +12V , -12V PS3 DC SUPPL Y +5V , +12V , -12V PS1 DC SUPPL Y 24V TB1 TERMINAL BLOCK CP1 – CP5 BREAKER M…
I/O Unit
LAF-10105-01
I/O Unit
SHEET
1/1
I/O Unit
LC
LED CONTROL BOARD III
CC
CONVEYOR CONTROL BOARD III-A
EL
EMG I/L BOARD II-A
SW LINK
SW LINK BOARD (OPTION)
Driver Unit
LAF-10106-01
Driver Unit
SHEET
1/1
Driver Unit
TB2
TERMINAL BLOCK
PS4
DC SUPPLY 48V
PS2
DC SUPPLY +5V, +12V, -12V
PS3
DC SUPPLY +5V, +12V, -12V
PS1
DC SUPPLY 24V
TB1
TERMINAL BLOCK
CP1 – CP5
BREAKER
MC1
MAGNETIC CONTACTOR
CR1
RELAY
DRV-P/B
PUSHER/BULK DRIVER BOARD
A
LM-IF
ALARM I/F BOARD II
DRV-AD
CONVEYOR ADJUSTMENT
MOTOR DRIVER
DRV-CE
CONVEYOR EJECT
MOTOR DRIVE BOARD
X-axis and Y-axis Circumference
LAF-10107-01
X-axis and Y-axis Circumference
SHEET
1/2
X-axis and Y-axis Circumference
< X-axis >
X-ORG
X-CCW
X-CW
X-ENCODER X-MOTOR
