X-axis and Y -axis Circumfer ence LAF-10107-01 X-axis and Y -axis Circumfe rence SHEET 2/2 < Y -axis > Y -CCW BULK-F SOLENOID V AL VE for FRONT BULK FEED Y- O R G BULK-R SOLENOID V AL VE for REAR BULK FEED H-LSB PD…
X-axis and Y-axis Circumference
LAF-10107-01
X-axis and Y-axis Circumference
SHEET
1/2
X-axis and Y-axis Circumference
< X-axis >
X-ORG
X-CCW
X-CW
X-ENCODER X-MOTOR
X-axis and Y-axis Circumference
LAF-10107-01
X-axis and Y-axis Circumference
SHEET
2/2
< Y-axis >
Y-CCW
BULK-F
SOLENOID VALVE for
FRONT BULK FEED
Y-ORG
BULK-R
SOLENOID VALVE for
REAR BULK FEED
H-LSB
PD-LSB
Y-CW
Y-MOTOR
Y-ENCODER
Rear side Front side
Head Unit Circumference
LAF-10108-01
Head Unit Circumference
SHEET
1/2
Head Unit Circumference
< Front side >
PARTS CAMER
A
PICK UP CAMER
A
R
T
-MOTOR
NOZZLE BACKWARD
DETECT (AMP)
R
T
-ENCODER
LED-2 for
PARTS CAMERA
LED-3 for
PARTS CAMERA
LED for PICK UP CAMER
A
LED (45°)
NOZZLE DIRECT
ENCODER
R
T
-ORG
BOARD CAMER
A
LED-1 for
BOARD CAMERA
RN-ORG
NOZZLE BACKWARD
DETECT
